Trim panel leg room for BMW 6 Series E24 633CSi (1979)
This Trim panel leg room technical drawing provides a detailed breakdown of the assembly for the 6 Series E24 633CSi. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1979.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Lateral trim panel front left | NYLONBRAUN | 1 | 09/1979 | 51431868073 | ENDED | Shop at ECS Tuning | |||
| 01 | Lateral trim panel front right | NYLONBRAUN | 1 | 09/1979 | 51431868074 | ENDED | Shop at ECS Tuning | |||
| 01 | Lateral trim panel front left | SCHWARZ | 1 | 09/1979 | 51431868075 | ENDED | Shop at ECS Tuning | |||
| 01 | Lateral trim panel front right | SCHWARZ | 1 | 09/1979 | 51431868076 | ENDED | Shop at ECS Tuning | |||
| 01 | Lateral trim panel front left | MARINEBLAU | 1 | 09/1979 | 51431868077 | ENDED | Shop at ECS Tuning | |||
| 01 | Lateral trim panel front right | MARINEBLAU | 1 | 09/1979 | 51431868078 | ENDED | Shop at ECS Tuning | |||
| 01 | Lateral trim panel front left | HELLGRAU | 1 | 09/1979 | 51431868079 | ENDED | Shop at ECS Tuning | |||
| 01 | Lateral trim panel front right | HELLGRAU | 1 | 09/1979 | 51431868080 | ENDED | Shop at ECS Tuning | |||
| 01 | Lateral trim panel front left | FARNGRUEN | 1 | 09/1979 | 51431868081 | ENDED | Shop at ECS Tuning | |||
| 01 | Lateral trim panel front right | FARNGRUEN | 1 | 09/1979 | 51431868082 | ENDED | Shop at ECS Tuning | |||
| 01 | Lateral trim panel front left | WEISSBEIGE | 1 | 09/1979 | 51431868083 | ENDED | Shop at ECS Tuning | |||
| 01 | Lateral trim panel front right | WESSBEIGE | 1 | 09/1979 | 51431868084 | ENDED | Shop at ECS Tuning |
Notes
- ENDED = the part has been discontinued (no longer available).
