Door window lifting mechanism front for BMW 3 Series E36 323i (1999)
This Door window lifting mechanism front technical drawing provides a detailed breakdown of the assembly for the 3 Series E36 323i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1999.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Bracket left | 1 | 51328151357 | $4.42 | Shop at ECS Tuning | |||||
| 01 | Bracket right | 1 | 51328151358 | $4.42 | ENDED | Shop at ECS Tuning | ||||
| 02 | Bracket left | 1 | 51321977813 | $5.90 | ENDED | Shop at ECS Tuning | ||||
| 02 | Bracket right | 1 | 51321977814 | $5.90 | Shop at ECS Tuning | |||||
| 03 | Left base | 2 | 51328151227 | $1.50 | Shop at ECS Tuning | |||||
| 03 | Right base | 2 | 51328151228 | $1.50 | Shop at ECS Tuning | |||||
| 04 | Bracket | 4 | 51328151226 | $3.23 | Shop at ECS Tuning | |||||
| 05 | Countersunk head screw | M6X25 | 4 | 07119901316 | $1.73 | Shop at ECS Tuning | ||||
| 05 | Hex bolt | M6 | 4 | 51328153040 | $0.66 | Shop at ECS Tuning | ||||
| 06 | Hex bolt with washer | M6X12-U2-8.8 | 4 | 07119904459 | $0.65 | Shop at ECS Tuning | ||||
| 07 | Hex bolt | M6X10-8.8-ZNS3 | 4 | 07119904633 | $0.20 | Shop at ECS Tuning | ||||
| 08 | Stopper | 4 | 51328151356 | $0.77 | Shop at ECS Tuning | |||||
| 09 | Hex bolt | M6X10 M. ANSATZ | 2 | 41518195403 | $0.25 | Shop at ECS Tuning | ||||
| 10 | Hex nut | M6-04-2-ZN | 4 | 07119921054 | $0.11 | Shop at ECS Tuning | ||||
| 11 | Fillister-head screw | M8 | 2 | 07147233975 | Shop at ECS Tuning | |||||
| 12 | Lock plate | 2 | 51338169501 | $2.18 | Shop at ECS Tuning | |||||
| 13 | Hex bolt | M6X10 | 4 | 51321977855 | $0.39 | Shop at ECS Tuning |
Notes
- ENDED = the part has been discontinued (no longer available).
