Door window lifting mechanism rear for BMW 3 Series E36 318ti (1996)
This Door window lifting mechanism rear technical drawing provides a detailed breakdown of the assembly for the 3 Series E36 318ti. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1996.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Green side window with left gasket | 1 | 51368242601 | $134.87 | ENDED | Shop at ECS Tuning | ||||
| 01 | Green side window with right gasket | 1 | 51368242602 | $134.87 | ENDED | Shop at ECS Tuning | ||||
| 02 | Hex nut with plate | AM6-8-ZNNIV SI | 4 | 07129904553 | $0.64 | Shop at ECS Tuning | ||||
| 03 | Hinge | 2 | 51368146803 | $21.44 | Shop at ECS Tuning | |||||
| 04 | Nut | 2 | 51368144980 | $2.40 | Shop at ECS Tuning | |||||
| 05 | Washer | 2 | 51368144798 | $0.47 | Shop at ECS Tuning | |||||
| 06 | Base | 2 | 51368144048 | $0.38 | Shop at ECS Tuning | |||||
| 07 | Countersunk head screw | 2 | 51368144046 | $0.39 | Shop at ECS Tuning | |||||
| 08 | Hex bolt | M5X14 | 4 | 07119904337 | $0.38 | Shop at ECS Tuning | ||||
| 10 | Washer | 5,3X20X1 | 4 | 51361960559 | $5.18 | Shop at ECS Tuning | ||||
| 11 | Expanding rivet | 4 | 51368192933 | $6.10 | Shop at ECS Tuning | |||||
| 12 | Edge protection left | 1 | 51728146765 | $39.72 | Shop at ECS Tuning | |||||
| 12 | Edge protection right | 1 | 51728146766 | $39.72 | Shop at ECS Tuning |
Notes
- ENDED = the part has been discontinued (no longer available).
