Aerokit, trim panel, rear for BMW MINI Clubman F54 One (2019)
This Aerokit, trim panel, rear technical drawing provides a detailed breakdown of the assembly for the MINI Clubman F54 One. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2019.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| For vehicles with JCW Aerodynamics kit and Park Distance Control (PDC), rear and Park Assistent |
S3A1A=Yes S507A=No S5DPA=No |
|||||||||
| 01 | Bumper trim panel, primed, rear | JCW | 1 | 51127450116 | Shop at ECS Tuning | |||||
| For vehicles with JCW Aerodynamics kit and Park Distance Control (PDC), rear and Park Assistent Important notice! Observe product information. Use "Only in conjunction with" parts. |
S3A1A=Yes S507A=No S5DPA=No |
|||||||||
| 01 | Bumper trim panel, primed, rear | JCW / PDC | 1 | 51127450117 | Shop at ECS Tuning | |||||
| only in conjunction with | ||||||||||
| -- | Decoupling ring PDC torque converter | 1 | 66209283203 | Shop at ECS Tuning | ||||||
| -- | Kit dummy trim | GEN 5.7.X | 1 | 51125A3F538 | Shop at ECS Tuning | |||||
| -- | Stick-on label | NO PDC | 1 | 01295A3BFA7 | Shop at ECS Tuning | |||||
| For vehicles with JCW Aerodynamics kit and Park Distance Control (PDC), rear and Park Assistent |
S3A1A=Yes S507A=Yes S5DPA=Yes |
|||||||||
| 01 | Bumper trim panel, primed, rear | JCW / PDC | 1 | 51127450117 | Shop at ECS Tuning | |||||
| For vehicles with JCW Aerodynamics kit and Park Distance Control (PDC), rear and Park Assistent |
S3A1A=Yes S507A=Yes S5DPA=No |
|||||||||
| 01 | Bumper trim panel, primed, rear | JCW / PDC | 1 | 51127450117 | Shop at ECS Tuning | |||||
| For vehicles with JCW Aerodynamics kit and Park Distance Control (PDC), rear and Park Assistent |
S3A1A=Yes S507A=No S5DPA=Yes |
|||||||||
| 01 | Bumper trim panel, primed, rear | JCW / PDC | 1 | 51127450117 | Shop at ECS Tuning | |||||
| For vehicles with JCW Aerodynamics kit |
S3A1A=Yes |
|||||||||
| 03 | Cover, tow fitting, primed, left | JCW | 1 | 51127448151 | Shop at ECS Tuning | |||||
| 03 | Cover, tow fitting, primed, right | JCW | 1 | 51127448152 | Shop at ECS Tuning | |||||
| 06 | Black band, rear lower left | 1 | 51127379907 | Shop at ECS Tuning | ||||||
| 06 | Black band, rear lower right | 1 | 51127379908 | Shop at ECS Tuning | ||||||
| For vehicles with MINI Cooper Untold Edition and JCW Aerodynamics kit |
P7GVA=No S3A1A=Yes |
|||||||||
| 06 | Black band, rear lower left | 1 | 51127379907 | Shop at ECS Tuning | ||||||
| 06 | Black band, rear lower right | 1 | 51127379908 | Shop at ECS Tuning | ||||||
| For vehicles with National version japan |
L807A=Yes |
|||||||||
| 07 | License plate bracket, rear | JAPAN | 1 | 51137176631 | Shop at ECS Tuning | |||||
| For vehicles with National version japan and Control of number-plate attachment |
L807A=No S992A=Yes |
|||||||||
| 07 | License-plate carrier rear | US | 1 | 51139448724 | Shop at ECS Tuning | |||||
| For vehicles with Reversing camera |
S3AGA=Yes |
|||||||||
| 08 | Mount for backup camera | 1 | 51127370614 | Shop at ECS Tuning | ||||||
| 09 | Cover for rearview camera | ICAM | 1 | 51247345709 | Shop at ECS Tuning | |||||
| 10 | Guide for bumper, side, left | 1 | 51127348901 | Shop at ECS Tuning | ||||||
| 10 | Guide for bumper, side, right | 1 | 51127348902 | Shop at ECS Tuning | ||||||
| 12 | Breather covering rear left | 1 | 51127432949 | Shop at ECS Tuning | ||||||
| 12 | Breather covering rear right | 1 | 51127432950 | Shop at ECS Tuning | ||||||
| 13 | Left protection foil | 1 | 51127427273 | Shop at ECS Tuning | ||||||
| 13 | Right protection foil | 1 | 51127427274 | Shop at ECS Tuning | ||||||
| 14 | Gasket ring | 6 | 51127256354 | Shop at ECS Tuning | ||||||
| 15 | Expanding rivet | D = 6MM | 6 | 51111908077 | $0.30 | Shop at ECS Tuning | ||||
| 16 | Expanding nut | 8X8 MM | 2 | 51127020321 | $0.47 | Shop at ECS Tuning | ||||
| 17 | Fillister head screw | 2 | 07147220383 | Shop at ECS Tuning | ||||||
| 18 | Clip, bottom part | 2 | 07147222908 | $1.28 | Shop at ECS Tuning | |||||
| 19 | Clip, upper part | 2 | 51497207958 | $1.97 | Shop at ECS Tuning | |||||
| 20 | Combination nut | 8 | 07147305178 | Shop at ECS Tuning | ||||||
| 21 | C-clip nut | 4 | 51717065773 | Shop at ECS Tuning | ||||||
| 22 | Hex bolt | TS5X20 SW8 D=22 | 6 | 07149213164 | $0.38 | Shop at ECS Tuning | ||||
| 23 | Expanding nut | ST 4.8 | 4 | 63121374075 | $0.23 | Shop at ECS Tuning | ||||
| 24 | Fillister head screw | ST5X17-ZNS3 | 4 | 07147127714 | $0.25 | Shop at ECS Tuning | ||||
| 25 | Screw | VS-TS5X16 SW | 2 | 51139908498 | Shop at ECS Tuning | |||||
