Trunk lid trim panel for BMW 2 Series F46 Gran Tourer LCI 218d (2022)
This Trunk lid trim panel technical drawing provides a detailed breakdown of the assembly for the 2 Series F46 Gran Tourer LCI 218d. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2022.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| For vehicles with automatic trunk lid mechanism |
S316A=No |
|||||||||
| 01 | Trim panel, trunk, lower inside | SCHWARZ | 1 | 51497414933 | Shop at ECS Tuning | |||||
| For vehicles with automatic trunk lid mechanism |
S316A=Yes |
|||||||||
| 01 | Trim panel, trunk, lower inside | SCHWARZ | 1 | 51497414937 | Shop at ECS Tuning | |||||
| 02 | Clip | 8 | 07147448866 | Shop at ECS Tuning | ||||||
| 03 | Expanding nut | 3 | 07146974274 | $3.75 | Shop at ECS Tuning | |||||
| 04 | Fillister head screw with collar | 2 | 07147402849 | Shop at ECS Tuning | ||||||
| 05 | Lens screw with base | VERKL. HKL | 1 | 51497445013 | Shop at ECS Tuning | |||||
| For vehicles with Headlining anthracite |
S775A=Yes |
|||||||||
| 06 | Trim panel for trunk, inner left | SCHWARZ | 1 | 51498065341 | Shop at ECS Tuning | |||||
| 06 | Trim panel for trunk, inner right | SCHWARZ | 1 | 51498065342 | Shop at ECS Tuning | |||||
| For vehicles with Headlining anthracite |
S775A=No |
|||||||||
| 06 | Trim panel for trunk, inner left | EVERESTGRAU | 1 | 51497403901 | Shop at ECS Tuning | |||||
| 06 | Trim panel for trunk, inner right | EVERESTGRAU | 1 | 51497403902 | Shop at ECS Tuning | |||||
| For vehicles with Headlining anthracite and canberra-beige or oyster/Akzent grau |
S775A=No CY=Yes OA=Yes |
|||||||||
| 06 | Trim panel for trunk, inner left | OYSTER | 1 | 51497403899 | Shop at ECS Tuning | |||||
| 06 | Trim panel for trunk, inner right | OYSTER | 1 | 51497403900 | Shop at ECS Tuning | |||||
| For vehicles with Headlining anthracite |
S775A=Yes |
|||||||||
| 07 | Interior upper trunk lid trim panel | SCHWARZ | 1 | 51498065340 | Shop at ECS Tuning | |||||
| For vehicles with Headlining anthracite |
S775A=No |
|||||||||
| 07 | Interior upper trunk lid trim panel | EVERESTGRAU | 1 | 51497402868 | Shop at ECS Tuning | |||||
| For vehicles with Headlining anthracite and canberra-beige or oyster/Akzent grau |
S775A=No CY=Yes OA=Yes |
|||||||||
| 07 | Interior upper trunk lid trim panel | OYSTER | 1 | 51497402867 | Shop at ECS Tuning | |||||
| 08 | Clip | 10 | 07147152593 | $0.17 | Shop at ECS Tuning | |||||
| 09 | Flap, bulb exchange, left | SCHWARZ | 1 | 51497414931 | Shop at ECS Tuning | |||||
| 09 | Flap, bulb exchange, right | SCHWARZ | 1 | 51497414932 | Shop at ECS Tuning | |||||
| 10 | Cover, catch bracket | SCHWARZ | 1 | 51497415738 | Shop at ECS Tuning | |||||
| 11 | Lamp, trunk light, left | 1 | 51497426495 | Shop at ECS Tuning | ||||||
| 11 | Lamp, trunk light, right | 1 | 51497426496 | Shop at ECS Tuning | ||||||
