Various mounted parts for BMW 3 Series E46 330Cd (2006)
This Various mounted parts technical drawing provides a detailed breakdown of the assembly for the 3 Series E46 330Cd. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2006.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Cover, windshield | 1 | 51718232896 | $57.86 | Shop at ECS Tuning | |||||
| 02 | Covering left | 1 | 51718208479 | $6.00 | Shop at ECS Tuning | |||||
| 02 | Covering right | 1 | 51718208480 | $6.00 | Shop at ECS Tuning | |||||
| 03 | Water outlet grommet | 2 | 51718204862 | $2.55 | Shop at ECS Tuning | |||||
| 04 | Dual clip | 2 | 51718177846 | $0.63 | Shop at ECS Tuning | |||||
| 05 | Left apron cover | 1 | 51718232635 | $6.00 | Shop at ECS Tuning | |||||
| 05 | Right apron cover | 1 | 51718232636 | $6.00 | Shop at ECS Tuning | |||||
| 06 | Left engine hood sealing | 1 | 51718215893 | $14.96 | Shop at ECS Tuning | |||||
| 06 | Right engine hood sealing | 1 | 51718215894 | $14.96 | Shop at ECS Tuning | |||||
| 07 | Rear engine hood sealing | 1 | 51718215919 | $14.96 | Shop at ECS Tuning | |||||
| 08 | Sealing, engine compartment left | 1 | 51718232085 | $20.31 | Shop at ECS Tuning | |||||
| 09 | Sealing, engine compartment right | 1 | 51718215914 | $24.52 | Shop at ECS Tuning | |||||
| 10 | seal, filter housing | 1 | 51718215915 | $19.68 | Shop at ECS Tuning | |||||
| 11 | Cover, wheelhousing liner, rear left | 1 | 51718224993 | $13.22 | Shop at ECS Tuning | |||||
| 11 | Cover, wheelhousing liner, rear right | 1 | 51718224994 | $22.66 | Shop at ECS Tuning | |||||
| 12 | Expanding rivet | D = 6MM | 2 | 51111908077 | $0.30 | Shop at ECS Tuning | ||||
| 12 | Expanding rivet | 2 | 51118174185 | $0.30 | Shop at ECS Tuning | |||||
| 14 | Plastic nut | 3 | 51711958025 | $0.26 | Shop at ECS Tuning | |||||
| 15 | Tank filler pot | 1 | 51718208646 | $14.42 | Shop at ECS Tuning | |||||
| 16 | Holder, spare-wheel bracket | 1 | 51718233827 | $12.49 | Shop at ECS Tuning | |||||
| 17 | Cap | 9 | 51718255004 | $0.33 | Shop at ECS Tuning | |||||
| 23 | Hex head screw | ST4,8X16-ZNS3 | 2 | 07119901299 | $0.25 | Shop at ECS Tuning |
