Door window lifting mechanism front for BMW 3 Series E46 325xi (2004)
This Door window lifting mechanism front technical drawing provides a detailed breakdown of the assembly for the 3 Series E46 325xi. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2004.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Cover, window frame with speaker, left | 1 | 51338212521 | $150.38 | Shop at ECS Tuning | |||||
| 01 | Cover, window frame with speaker, right | 1 | 51338212522 | $150.38 | Shop at ECS Tuning | |||||
| For vehicles with Hi-Fi System Harman Kardon |
S674A=Yes |
|||||||||
| 01 | Cover, window frame with speaker, left | HARMAN KARDON | 1 | 51338234629 | $150.38 | Shop at ECS Tuning | ||||
| 01 | Cover, window frame with speaker, right | HARMAN KARDON | 1 | 51338234630 | $150.38 | Shop at ECS Tuning | ||||
| 02 | Clip | 2 | 51348204145 | $0.42 | Shop at ECS Tuning | |||||
| 03 | Plug-in retainer | 2 | 07146957034 | $0.25 | Shop at ECS Tuning | |||||
| 04 | Sealing front | 1 | 51338238887 | $9.59 | Shop at ECS Tuning | |||||
| 04 | SEALING FRONT right | 1 | 51338238888 | $9.59 | Shop at ECS Tuning | |||||
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 3 Series E46 325xi Door window lifting mechanism front?
- This technical diagram illustrates the Door window lifting mechanism front within the Vehicle trim group for the 3 Series E46 325xi produced during 2004. It provides a detailed exploded view of the components, identifying key parts such as the Cover, window frame with speaker, left (Part #51338212521).
- Which models use the hardware listed in this Door window lifting mechanism front?
- The hardware and components featured in the Door window lifting mechanism front are specific to the 3 Series E46 325xi produced during 2004. These technical specifications ensure that parts like the Cover, window frame with speaker, left (51338212521) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Door window lifting mechanism front assembly?
- Each item in the Door window lifting mechanism front corresponds to the numbered list below the illustration. For the 3 Series E46 325xi, you can identify the Cover, window frame with speaker, left by locating its position on the schematic, which then links to the official BMW part number 51338212521 for the Vehicle trim section.
