Bumper rear for BMW 1502-2002tii 2002ti (1972)
This Bumper rear technical drawing provides a detailed breakdown of the assembly for the 1502-2002tii 2002ti. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1972.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 03 | Washer | A6,4-ZNNIV SI | 4 | 07119904202 | Shop at ECS Tuning | |||||
| 04 | Self-locking hex nut | M6 | 4 | 64509123157 | $0.70 | Shop at ECS Tuning | ||||
| 05 | Rubber buffer | 2 | 51119558125 | $30.34 | Shop at ECS Tuning | |||||
| 06 | Saucer-head screw | M8X65 | 2 | 07119910474 | $1.21 | Shop at ECS Tuning |
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 1502-2002tii 2002ti Bumper rear?
- This technical diagram illustrates the Bumper rear within the Vehicle trim group for the 1502-2002tii 2002ti produced during 1972. It provides a detailed exploded view of the components, identifying key parts such as the Washer (Part #07119904202).
- Which models use the hardware listed in this Bumper rear?
- The hardware and components featured in the Bumper rear are specific to the 1502-2002tii 2002ti produced during 1972. These technical specifications ensure that parts like the Washer (07119904202) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Bumper rear assembly?
- Each item in the Bumper rear corresponds to the numbered list below the illustration. For the 1502-2002tii 2002ti, you can identify the Washer by locating its position on the schematic, which then links to the official BMW part number 07119904202 for the Vehicle trim section.
