Armrest-single parts for BMW 2.5CS-3.0CSL 3.0CSiL (1975)
This Armrest-single parts technical drawing provides a detailed breakdown of the assembly for the 2.5CS-3.0CSL 3.0CSiL. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1975.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Screw | M 3 X 13 | 2 | 07119915615 | ENDED | Shop at ECS Tuning | ||||
| 02 | Fillister head self-tapping screw | ST5,5X38 | 4 | 07119907782 | ENDED | Shop at ECS Tuning | ||||
| 03 | Fillister head self-tapping screw | ST5,5X38 | 2 | 07119907782 | ENDED | Shop at ECS Tuning | ||||
| 04 | Clamp | 14 | 51411870718 | $0.24 | Shop at ECS Tuning | |||||
| 05 | Clamp | 14 | 51411870718 | $0.24 | Shop at ECS Tuning | |||||
| 06 | Waist rail trim strip | 1 | 51216754260 | ENDED | Shop at ECS Tuning | |||||
| 06 | Waist rail trim strip | 1 | 51216754261 | ENDED | Shop at ECS Tuning | |||||
| 07 | Clamp | 2 | 51327441122 | $0.30 | Shop at ECS Tuning | |||||
| 08 | Clamp | 8 | 51216754263 | ENDED | Shop at ECS Tuning | |||||
| 09 | Fillister head screw | M5X25 | 2 | 07119907634 | ENDED | Shop at ECS Tuning |
Notes
- ENDED = the part has been discontinued (no longer available).
