Ashtray rear for BMW 2500-3.3Li 3.0Si (1973)
This Ashtray rear technical drawing provides a detailed breakdown of the assembly for the 2500-3.3Li 3.0Si. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1973.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Ashtray rear | SCHWARZ | 2 | 51161804983 | ENDED | Shop at ECS Tuning | ||||
| 02 | Fillister head self-tapping screw | ST4,2X9,5 | 4 | 07119907741 | $0.09 | ENDED | Shop at ECS Tuning |
Notes
- ENDED = the part has been discontinued (no longer available).
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 2500-3.3Li 3.0Si Ashtray rear?
- This technical diagram illustrates the Ashtray rear within the Vehicle trim group for the 2500-3.3Li 3.0Si produced during 1973. It provides a detailed exploded view of the components, identifying key parts such as the Ashtray rear (Part #51161804983).
- Which models use the hardware listed in this Ashtray rear?
- The hardware and components featured in the Ashtray rear are specific to the 2500-3.3Li 3.0Si produced during 1973. These technical specifications ensure that parts like the Ashtray rear (51161804983) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Ashtray rear assembly?
- Each item in the Ashtray rear corresponds to the numbered list below the illustration. For the 2500-3.3Li 3.0Si, you can identify the Ashtray rear by locating its position on the schematic, which then links to the official BMW part number 51161804983 for the Vehicle trim section.
