Roof moulding/Roof rail for BMW 5 Series G30 LCI 545eX (2023)
This Roof moulding/Roof rail technical drawing provides a detailed breakdown of the assembly for the 5 Series G30 LCI 545eX. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2023.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Roof molding prime-coated left | 1 | 51137443691 | Shop at ECS Tuning | ||||||
| 01 | Roof molding prime-coated right | 1 | 51137443692 | Shop at ECS Tuning | ||||||
| 03 | Clip | 10 | 51137357283 | Shop at ECS Tuning | ||||||
| 04 | Clip | 14 | 51137472264 | Shop at ECS Tuning |
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 5 Series G30 LCI 545eX Roof moulding/Roof rail?
- This technical diagram illustrates the Roof moulding/Roof rail within the Vehicle trim group for the 5 Series G30 LCI 545eX produced during 2023. It provides a detailed exploded view of the components, identifying key parts such as the Roof molding prime-coated left (Part #51137443691).
- Which models use the hardware listed in this Roof moulding/Roof rail?
- The hardware and components featured in the Roof moulding/Roof rail are specific to the 5 Series G30 LCI 545eX produced during 2023. These technical specifications ensure that parts like the Roof molding prime-coated left (51137443691) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Roof moulding/Roof rail assembly?
- Each item in the Roof moulding/Roof rail corresponds to the numbered list below the illustration. For the 5 Series G30 LCI 545eX, you can identify the Roof molding prime-coated left by locating its position on the schematic, which then links to the official BMW part number 51137443691 for the Vehicle trim section.
