Handle for BMW 3 Series E46 M3 (2002)
This Handle technical drawing provides a detailed breakdown of the assembly for the 3 Series E46 M3. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2002.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Handle front - ITS | SCHWARZ | 1 | 51162699050 | $34.50 | ENDED | Shop at ECS Tuning | |||
| 01 | Handle front - ITS | HELLGRAU | 1 | 51168231322 | $34.50 | Shop at ECS Tuning | ||||
| 02 | Frame | SCHWARZ | 2 | 51162699052 | $0.73 | Shop at ECS Tuning | ||||
| 02 | Frame | HELLGRAU | 2 | 51448250141 | $1.05 | Shop at ECS Tuning | ||||
| 03 | Sheet metal screw | ST 4,8X13-C-U1 | 2 | 07119906163 | $0.71 | Shop at ECS Tuning | ||||
| 04 | Cap | SCHWARZ | 2 | 51162699051 | $0.92 | ENDED | Shop at ECS Tuning | |||
| 04 | Cap | HELLGRAU | 2 | 51168244447 | $1.08 | Shop at ECS Tuning | ||||
| 05 | Bracket f left handle ITS | 2 | 51168222649 | $2.77 | Shop at ECS Tuning | |||||
| 05 | Bracket f right handle ITS | 2 | 51168222650 | $2.77 | Shop at ECS Tuning | |||||
| 06 | Clothes hook | SCHWARZ | 2 | 51169150380 | $13.27 | Shop at ECS Tuning | ||||
| 06 | Clothes hook | HELLGRAU | 2 | 51169150388 | $8.90 | Shop at ECS Tuning | ||||
| 06 | Clothes hook | HELLBEIGE | 2 | 51169150389 | $13.27 | Shop at ECS Tuning | ||||
| 07 | Bracket left | 1 | 51167000689 | $10.74 | ENDED | Shop at ECS Tuning | ||||
| 07 | Bracket right | 1 | 51167000690 | $10.74 | Shop at ECS Tuning | |||||
| 07 | Bracket clothing hook ITS left | 1 | 51168223047 | $1.68 | Shop at ECS Tuning | |||||
| 07 | Bracket clothing hook ITS right | 1 | 51168223048 | $1.68 | Shop at ECS Tuning | |||||
| For vehicles with Glass roof, electrical |
S403A=Yes |
|||||||||
| 07 | Bracket clothing hook ITS left | 1 | 51168222915 | $1.68 | ENDED | Shop at ECS Tuning | ||||
| 07 | Bracket clothing hook ITS right | 1 | 51168222916 | $1.68 | ENDED | Shop at ECS Tuning | ||||
| 08 | Fillister head self-tapping screw | ST4,8X13 | 14 | 07119907786 | $0.11 | Shop at ECS Tuning | ||||
| 09 | Plug-in nut | M5 | 4 | 46637651465 | $1.29 | Shop at ECS Tuning | ||||
| 10 | Hex head screw | ST4,8X19 | 2 | 07119904183 | $0.17 | Shop at ECS Tuning | ||||
| 10 | Sheet metal screw | ST4,8X19 SW | 6 | 07119904255 | $0.20 | Shop at ECS Tuning | ||||
| 11 | Cover, handle cut-out | HELLGRAU | 2 | 04/1999 | 51167010926 | $0.56 | Shop at ECS Tuning | |||
| 11 | Cover, handle cut-out | SCHWARZ | 2 | 04/1999 | 51167010928 | $0.56 | Shop at ECS Tuning | |||
| 12 | Cable clamp | D=12MM | 1 | 61131354602 | $0.44 | Shop at ECS Tuning | ||||
Notes
- ENDED = the part has been discontinued (no longer available).
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 3 Series E46 M3 Handle?
- This technical diagram illustrates the Handle within the Vehicle trim group for the 3 Series E46 M3 produced during 2002. It provides a detailed exploded view of the components, identifying key parts such as the Handle front - ITS (Part #51162699050).
- Which models use the hardware listed in this Handle?
- The hardware and components featured in the Handle are specific to the 3 Series E46 M3 produced during 2002. These technical specifications ensure that parts like the Handle front - ITS (51162699050) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Handle assembly?
- Each item in the Handle corresponds to the numbered list below the illustration. For the 3 Series E46 M3, you can identify the Handle front - ITS by locating its position on the schematic, which then links to the official BMW part number 51162699050 for the Vehicle trim section.
