Trim and seals for door, rear for BMW 3 Series E46 316i (2005)
This Trim and seals for door, rear technical drawing provides a detailed breakdown of the assembly for the 3 Series E46 316i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2005.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Cover, window frame with speaker, left | 1 | 51348262717 | Shop at ECS Tuning | ||||||
| 01 | Cover, window frame with speaker, right | 1 | 51348262718 | Shop at ECS Tuning | ||||||
| For vehicles with Window lifts,electric,front/rear |
S411A=Yes |
|||||||||
| 01 | Cover, window frame with speaker, left | 1 | 51358212525 | $78.37 | Shop at ECS Tuning | |||||
| 01 | Cover, window frame with speaker, right | 1 | 51358212526 | $78.37 | Shop at ECS Tuning | |||||
| 02 | Plug-in retainer | 2 | 07146957034 | $0.25 | Shop at ECS Tuning | |||||
| 03 | Sealing tape | 1 M | 1 | 51347007482 | $1.97 | Shop at ECS Tuning | ||||
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 3 Series E46 316i Trim and seals for door, rear?
- This technical diagram illustrates the Trim and seals for door, rear within the Vehicle trim group for the 3 Series E46 316i produced during 2005. It provides a detailed exploded view of the components, identifying key parts such as the Cover, window frame with speaker, left (Part #51348262717).
- Which models use the hardware listed in this Trim and seals for door, rear?
- The hardware and components featured in the Trim and seals for door, rear are specific to the 3 Series E46 316i produced during 2005. These technical specifications ensure that parts like the Cover, window frame with speaker, left (51348262717) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Trim and seals for door, rear assembly?
- Each item in the Trim and seals for door, rear corresponds to the numbered list below the illustration. For the 3 Series E46 316i, you can identify the Cover, window frame with speaker, left by locating its position on the schematic, which then links to the official BMW part number 51348262717 for the Vehicle trim section.
