Underhood shield for BMW MINI Countryman F60 LCI Cooper (2023)
This Underhood shield technical drawing provides a detailed breakdown of the assembly for the MINI Countryman F60 LCI Cooper. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2023.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| For vehicles with Skid plate national versions |
S8SDA=Yes |
|||||||||
| 01 | Underhood shield | 1 | 51757366682 | Shop at ECS Tuning | ||||||
| For vehicles with National version China and Skid plate national versions |
L8AAA=No S8SDA=Yes |
|||||||||
| 01 | Underhood shield | 1 | 51757366682 | Shop at ECS Tuning | ||||||
| 05 | Rotary clip | 2 | 51757163899 | $1.44 | Shop at ECS Tuning | |||||
| 06 | Hex bolt | M6X20-8.8 | 10 | 07119907898 | Shop at ECS Tuning | |||||
| 07 | Hex bolt | TS5X17 SW8 D=22 | 4 | 07149126886 | Shop at ECS Tuning | |||||
| 08 | Clip nut | M6 | 4 | 41357060601 | $0.70 | Shop at ECS Tuning | ||||
| 09 | C-clip nut | 4 | 51717065773 | Shop at ECS Tuning | ||||||
| 10 | Blind rivet nut, flat headed | M6 | 4 | 07147311614 | Shop at ECS Tuning | |||||
| 11 | Expanding nut | L= 19.9MM | 4 | 07147306224 | Shop at ECS Tuning | |||||
| 12 | C-clip for plastic nut | TS5 | 4 | 07147311312 | Shop at ECS Tuning | |||||
See Also
Frequently Asked Questions
- What assembly is shown in the BMW MINI Countryman F60 LCI Cooper Underhood shield?
- This technical diagram illustrates the Underhood shield within the Vehicle trim group for the MINI Countryman F60 LCI Cooper produced during 2023. It provides a detailed exploded view of the components, identifying key parts such as the Underhood shield (Part #51757366682).
- Which models use the hardware listed in this Underhood shield?
- The hardware and components featured in the Underhood shield are specific to the MINI Countryman F60 LCI Cooper produced during 2023. These technical specifications ensure that parts like the Underhood shield (51757366682) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Underhood shield assembly?
- Each item in the Underhood shield corresponds to the numbered list below the illustration. For the MINI Countryman F60 LCI Cooper, you can identify the Underhood shield by locating its position on the schematic, which then links to the official BMW part number 51757366682 for the Vehicle trim section.
