Trim panel for decor elements front JCW for BMW MINI Countryman F60 One (2020)
This Trim panel for decor elements front JCW technical drawing provides a detailed breakdown of the assembly for the MINI Countryman F60 One. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2020.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Decorative grill hood | BASIS | 1 | 51137405396 | Shop at ECS Tuning | |||||
| For vehicles with Chrome Line exterieur |
S346A=Yes |
|||||||||
| 01 | Decorative grill hood | CHROM | 1 | 51137405407 | Shop at ECS Tuning | |||||
| For vehicles with JCW Aerodynamics kit and Park Distance Control (PDC) and Park Assistent |
S3A1A=Yes S508A=No S5DPA=No |
|||||||||
| 02 | Grid, center | JCW | 1 | 51117390547 | Shop at ECS Tuning | |||||
| For vehicles with JCW Aerodynamics kit and Park Distance Control (PDC) and Park Assistent |
S3A1A=Yes S508A=Yes S5DPA=Yes |
|||||||||
| 02 | Grid, center | JCW / PDC | 1 | 51117390548 | Shop at ECS Tuning | |||||
| For vehicles with JCW Aerodynamics kit and Park Distance Control (PDC) and Park Assistent |
S3A1A=Yes S508A=Yes S5DPA=No |
|||||||||
| 02 | Grid, center | JCW / PDC | 1 | 51117390548 | Shop at ECS Tuning | |||||
| For vehicles with JCW Aerodynamics kit and Park Distance Control (PDC) and Park Assistent |
S3A1A=Yes S508A=No S5DPA=Yes |
|||||||||
| 02 | Grid, center | JCW / PDC | 1 | 51117390548 | Shop at ECS Tuning | |||||
| For vehicles with JCW Aerodynamics kit |
S3A1A=Yes |
|||||||||
| 03 | Spoiler, front | JCW | 1 | 51117390543 | Shop at ECS Tuning | |||||
| 03 | Spoiler, front | JCW / PDC | 1 | 51117478631 | Shop at ECS Tuning | |||||
| 04 | Trim for front light left | JCW / OFFEN | 1 | 51117390549 | Shop at ECS Tuning | |||||
| 04 | Trim for front light right | JCW | 1 | 51117390554 | Shop at ECS Tuning | |||||
| For vehicles with National version China |
L8AAA=Yes |
|||||||||
| 05 | License-plate carrier front | 1 | 51117431162 | Shop at ECS Tuning | ||||||
| For vehicles with National version japan or Control of number-plate attachment |
L807A=Yes S992A=Yes |
|||||||||
| 05 | License-plate carrier front | 1 | 51117431159 | Shop at ECS Tuning | ||||||
| 06 | Screw | M6X20 | 8 | 07119908722 | Shop at ECS Tuning | |||||
| 07 | Expanding rivet | L = 11MM | 2 | 07149807127 | Shop at ECS Tuning | |||||
| 08 | Expanding rivet | D = 6MM | 2 | 51111908077 | $0.30 | Shop at ECS Tuning | ||||
| 09 | Hex bolt | TS5X17 SW8 D=22 | 10 | 07149126886 | Shop at ECS Tuning | |||||
| 10 | Screw | 6X20 | 2 | 07129907489 | Shop at ECS Tuning | |||||
| 11 | Phillips screw f plastic material | TS 5X13 | 2 | 07146959892 | $0.30 | Shop at ECS Tuning | ||||
See Also
Frequently Asked Questions
- What assembly is shown in the BMW MINI Countryman F60 One Trim panel for decor elements front JCW?
- This technical diagram illustrates the Trim panel for decor elements front JCW within the Vehicle trim group for the MINI Countryman F60 One produced during 2020. It provides a detailed exploded view of the components, identifying key parts such as the Decorative grill hood (Part #51137405396).
- Which models use the hardware listed in this Trim panel for decor elements front JCW?
- The hardware and components featured in the Trim panel for decor elements front JCW are specific to the MINI Countryman F60 One produced during 2020. These technical specifications ensure that parts like the Decorative grill hood (51137405396) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Trim panel for decor elements front JCW assembly?
- Each item in the Trim panel for decor elements front JCW corresponds to the numbered list below the illustration. For the MINI Countryman F60 One, you can identify the Decorative grill hood by locating its position on the schematic, which then links to the official BMW part number 51137405396 for the Vehicle trim section.
