Trim cover, rear for BMW 5 Series E61 LCI 530d (2010)
This Trim cover, rear technical drawing provides a detailed breakdown of the assembly for the 5 Series E61 LCI 530d. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2010.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| i | For vehicles with M Sports package and M Aerodynamics package and Aerodynamics package |
P337A=No S715A=No S716A=No |
||||||||
| Important notice! Observe product information. Use "Only in conjunction with" parts. |
||||||||||
| 01 | Bumper trim panel, primed, rear | PDC | 1 | 51127117277 | $623.02 | +core | Shop at ECS Tuning | |||
| only in conjunction with | ||||||||||
| -- | Kit dummy trim | GEN 4.2 | 1 | 51125A3F542 | Shop at ECS Tuning | |||||
| For vehicles with Park Distance Control (PDC) |
S508A=Yes |
|||||||||
| 01 | Bumper trim panel, primed, rear | PDC | 1 | 03/2007 | 51127184750 | $623.02 | +core | Shop at ECS Tuning | ||
| 02 | Flap, towing eye, primed | 1 | 51127117280 | $12.39 | Shop at ECS Tuning | |||||
| For vehicles with Towing hitch, detachable |
S235A=Yes |
|||||||||
| 04 | Trailer hitch flap, prime-coated | 1 | 51127126377 | $30.88 | +core | Shop at ECS Tuning | ||||
| 05 | Rear ventilation | 2 | 03/2007 | 64226945845 | $19.07 | Shop at ECS Tuning | ||||
| For vehicles with Park Distance Control (PDC) |
S508A=Yes |
|||||||||
| 06 | Mount for PDC sensor, rear | PDC | 4 | 03/2007 | 51127178177 | $8.95 | Shop at ECS Tuning | |||
Notes
- +core = plus core charge (possibility of a return of the old part)
