Trim, decor elements, rear for BMW 1 Series E82 135i (2010)
This Trim, decor elements, rear technical drawing provides a detailed breakdown of the assembly for the 1 Series E82 135i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2010.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Guide, center rear | 1 | 51127170665 | $15.04 | Shop at ECS Tuning | |||||
| 03 | Guide left | -M- | 1 | 51128045507 | $16.39 | Shop at ECS Tuning | ||||
| 03 | Guide right | -M- | 1 | 51128045508 | $16.39 | Shop at ECS Tuning | ||||
| 04 | Plastic capnut with washer | D=22MM | 6 | 07147169847 | $0.36 | Shop at ECS Tuning | ||||
| 06 | C-clip nut, self-locking | ST 4.8 -ZNS3 | 10 | 07146951655 | $0.20 | Shop at ECS Tuning | ||||
| 06 | C-clip nut, self-locking | TS5 | 10 | 07147330004 | Shop at ECS Tuning | |||||
| 07 | Hex head screw | ST4,8X16-ZNS3 | 10 | 07119901299 | $0.25 | Shop at ECS Tuning | ||||
| 11 | Sealing strip | 2 | 51129123785 | $0.45 | Shop at ECS Tuning |
