Trim, decor elements, front for BMW 1 Series E87 LCI 118i (2009)
This Trim, decor elements, front technical drawing provides a detailed breakdown of the assembly for the 1 Series E87 LCI 118i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2009.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| i | Not suitable for aerodynamic package For vehicles with Park Distance Control (PDC), rear or Park Distance Control (PDC) |
S507A=Yes S508A=Yes |
||||||||
| 01 | Bracket PDC front exterior, left | 1 | 03/2007 | 51117182365 | Shop at ECS Tuning | |||||
| 01 | Bracket PDC front exterior, right | 1 | 03/2007 | 51117182366 | Shop at ECS Tuning | |||||
| 02 | Bracket PDC front interior, left | 1 | 03/2007 | 51117182363 | Shop at ECS Tuning | |||||
| 02 | Bracket PDC front interior, right | 1 | 03/2007 | 51117182364 | Shop at ECS Tuning | |||||
| 03 | Bracket, PDC-sensor rear exterior left | 1 | 03/2007 | 51127176699 | Shop at ECS Tuning | |||||
| 03 | Bracket, PDC-sensor rear exterior right | 1 | 03/2007 | 51127176700 | Shop at ECS Tuning | |||||
| 04 | Bracket, PDC-sensor rear interior left | 1 | 03/2007 | 51127176697 | Shop at ECS Tuning | |||||
| 04 | Bracket, PDC-sensor rear interior right | 1 | 03/2007 | 51127176698 | Shop at ECS Tuning | |||||
