Door window lifting mechanism front for BMW 1 Series E87 118d (2007)
This Door window lifting mechanism front technical drawing provides a detailed breakdown of the assembly for the 1 Series E87 118d. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2007.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| with Cover for speaker |
||||||||||
| 01 | Cover, window frame, door front left | 1 | 07/2009 | 51337258571 | ENDED | Shop at ECS Tuning | ||||
| WITHOUT Cover for speaker Loudspeaker not included in supplied package |
||||||||||
| 01 | Cover, window frame, door front left | 1 | 51337258573 | Shop at ECS Tuning | ||||||
| 01 | Cover, window frame, door front right | 1 | 51337258574 | Shop at ECS Tuning | ||||||
| 02 | Seal, inner left mirror triangle | 1 | 51337059341 | Shop at ECS Tuning | ||||||
| 02 | Seal, inner right mirror triangle | 1 | 51337059342 | Shop at ECS Tuning | ||||||
| 03 | Clamp | 9 | 51337121160 | ENDED | Shop at ECS Tuning | |||||
| Depending on equipment, the respective window frame cover must be ordered! |
||||||||||
| 03 | Clamp | 9 | 51357135518 | Shop at ECS Tuning | ||||||
| only in conjunction with | ||||||||||
| -- | Cover, window frame, door front left | 1 | 51337258573 | Shop at ECS Tuning | ||||||
| -- | Cover, window frame, door front right | 1 | 51337258574 | Shop at ECS Tuning | ||||||
| -- | Cover, window frame, door front left | HARMAN/KARDON | 1 | 51337270887 | Shop at ECS Tuning | |||||
| -- | Cover, window frame, door front right | HARMAN/KARDON | 1 | 51337270888 | Shop at ECS Tuning | |||||
| 04 | Plug-in retainer | 3 | 07146957034 | $0.25 | Shop at ECS Tuning | |||||
| For vehicles with HiFi speaker system or HiFi System Professional DSP |
S676A=Yes S677A=Yes |
|||||||||
| 05 | Grill cover, left | 1 | 51337077179 | Shop at ECS Tuning | ||||||
| 05 | Grill cover, right | 1 | 51337077180 | Shop at ECS Tuning | ||||||
Notes
- ENDED = the part has been discontinued (no longer available).
