Vibration damper for BMW 4 Series F33 440iX (2017)
This Vibration damper technical drawing provides a detailed breakdown of the assembly for the 4 Series F33 440iX. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2017.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Battery tray | 1 | 51717188481 | $47.54 | Shop at ECS Tuning | |||||
| 02 | Vibration absorber | 1 | 51717395739 | Shop at ECS Tuning | ||||||
| 03 | Battery strip terminal | 1 | 51717188488 | $9.92 | Shop at ECS Tuning | |||||
| 04 | Mounting screw | 2 | 61217573350 | $4.63 | Shop at ECS Tuning | |||||
| 05 | O-ring | 5X2 | 2 | 11421284113 | $0.79 | Shop at ECS Tuning | ||||
| 08 | Hex nut with plate | M8-Z2 | 4 | 07147144953 | $0.82 | Shop at ECS Tuning | ||||
| 09 | Hex bolt with washer | ISA M8X18 | 5 | 07147122479 | $1.16 | Shop at ECS Tuning |
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 4 Series F33 440iX Vibration damper?
- This technical diagram illustrates the Vibration damper within the Vehicle trim group for the 4 Series F33 440iX produced during 2017. It provides a detailed exploded view of the components, identifying key parts such as the Battery tray (Part #51717188481).
- Which models use the hardware listed in this Vibration damper?
- The hardware and components featured in the Vibration damper are specific to the 4 Series F33 440iX produced during 2017. These technical specifications ensure that parts like the Battery tray (51717188481) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Vibration damper assembly?
- Each item in the Vibration damper corresponds to the numbered list below the illustration. For the 4 Series F33 440iX, you can identify the Battery tray by locating its position on the schematic, which then links to the official BMW part number 51717188481 for the Vehicle trim section.
