Trim cover, front for BMW 3 Series E90 LCI 325i (2009)
This Trim cover, front technical drawing provides a detailed breakdown of the assembly for the 3 Series E90 LCI 325i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2009.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| For vehicles with Headlight cleaning system and Park Distance Control (PDC) Important notice! Observe product information. Use "Only in conjunction with" parts. |
S502A=Yes S508A=No |
|||||||||
| 01 | Trim cover, bumper, primed, front | SRA+PDC | 1 | 51117204249 | $443.05 | Shop at ECS Tuning | ||||
| only in conjunction with | ||||||||||
| -- | Decoupling ring PDC torque converter | 4 | 66206923000 | $1.05 | Shop at ECS Tuning | |||||
| -- | Kit dummy trim | GEN 4 | 1 | 51125A3F536 | Shop at ECS Tuning | |||||
| -- | Set of mounted parts, bumper, front | VALUE PARTS | 1 | 51112410006 | Shop at ECS Tuning | |||||
| -- | Stick-on label | NO PDC | 1 | 01295A3BFA7 | Shop at ECS Tuning | |||||
| For vehicles with Headlight cleaning system and Park Distance Control (PDC) |
S502A=No S508A=Yes |
|||||||||
| 01 | Trim cover, bumper, primed, front | -PDC- | 1 | 51117204247 | Shop at ECS Tuning | |||||
| only in conjunction with | ||||||||||
| -- | Set of mounted parts, bumper, front | VALUE PARTS | 1 | 51112410006 | Shop at ECS Tuning | |||||
| For vehicles with Headlight cleaning system and Park Distance Control (PDC) Important notice! Observe product information. Use "Only in conjunction with" parts. |
S502A=Yes S508A=No |
|||||||||
| 01 | Trim cover, bumper, primed, front | -PDC- | 1 | 51117204247 | Shop at ECS Tuning | |||||
| only in conjunction with | ||||||||||
| -- | Decoupling ring PDC torque converter | 4 | 66206923000 | $1.05 | Shop at ECS Tuning | |||||
| -- | Kit dummy trim | GEN 4 | 1 | 51125A3F536 | Shop at ECS Tuning | |||||
| -- | Set of mounted parts, bumper, front | VALUE PARTS | 1 | 51112410006 | Shop at ECS Tuning | |||||
| -- | Stick-on label | NO PDC | 1 | 01295A3BFA7 | Shop at ECS Tuning | |||||
| For vehicles with Headlight cleaning system and Park Distance Control (PDC) Important notice! Observe product information. Use "Only in conjunction with" parts. |
S502A=No S508A=Yes |
|||||||||
| 01 | Trim cover, bumper, primed, front | -PDC- | 1 | 51117204247 | Shop at ECS Tuning | |||||
| only in conjunction with | ||||||||||
| -- | Decoupling ring PDC torque converter | 4 | 66206923000 | $1.05 | Shop at ECS Tuning | |||||
| -- | Kit dummy trim | GEN 4 | 1 | 51125A3F536 | Shop at ECS Tuning | |||||
| -- | Set of mounted parts, bumper, front | VALUE PARTS | 1 | 51112410006 | Shop at ECS Tuning | |||||
| -- | Stick-on label | NO PDC | 1 | 01295A3BFA7 | Shop at ECS Tuning | |||||
| For vehicles with Headlight cleaning system and Park Distance Control (PDC) Important notice! Observe product information. Use "Only in conjunction with" parts. |
S502A=No S508A=No |
|||||||||
| 01 | Trim cover, bumper, primed, front | -PDC- | 1 | 51117204247 | Shop at ECS Tuning | |||||
| only in conjunction with | ||||||||||
| -- | Decoupling ring PDC torque converter | 4 | 66206923000 | $1.05 | Shop at ECS Tuning | |||||
| -- | Kit dummy trim | GEN 4 | 1 | 51125A3F536 | Shop at ECS Tuning | |||||
| -- | Set of mounted parts, bumper, front | VALUE PARTS | 1 | 51112410006 | Shop at ECS Tuning | |||||
| -- | Stick-on label | NO PDC | 1 | 01295A3BFA7 | Shop at ECS Tuning | |||||
| For vehicles with Headlight cleaning system and Park Distance Control (PDC) |
S502A=Yes S508A=Yes |
|||||||||
| 01 | Trim cover, bumper, primed, front | SRA+PDC | 1 | 51117204249 | $443.05 | Shop at ECS Tuning | ||||
| only in conjunction with | ||||||||||
| -- | Set of mounted parts, bumper, front | VALUE PARTS | 1 | 51112410006 | Shop at ECS Tuning | |||||
| Only for vehicles with front fog lamps with Brake ventilation duct |
||||||||||
| 03 | Partially open grid, left | 1 | 09/2008 | 51117198901 | $23.16 | Shop at ECS Tuning | ||||
| 03 | Partially open grid, right | 1 | 09/2008 | 51117198902 | $23.16 | Shop at ECS Tuning | ||||
| 04 | Grid, center open | 1 | 51117198906 | $23.16 | Shop at ECS Tuning | |||||
| For vehicles with Active cruise control |
S541A=Yes |
|||||||||
| 04 | Grid, center | ACC | 1 | 51117054459 | $23.16 | Shop at ECS Tuning | ||||
| 05 | Cover | ACC | 1 | 51117054460 | $9.52 | Shop at ECS Tuning | ||||
| Only for vehicles with front fog lamps | ||||||||||
| 07 | Finisher, rod, left | SCHWARZ | 1 | 51117198899 | $6.22 | Shop at ECS Tuning | ||||
| 07 | Finisher, rod, right | SCHWARZ | 1 | 51117198900 | $6.22 | Shop at ECS Tuning | ||||
| For vehicles with Exclusive Edition or Lifestyle Edition or M Aerodynamics package Only for vehicles with front fog lamps |
P7MCA=Yes P7MDA=Yes S715A=Yes |
|||||||||
| 07 | Finisher, rod, left | ALU MATT | 1 | 51117198903 | $18.13 | Shop at ECS Tuning | ||||
| 07 | Finisher, rod, right | ALU MATT | 1 | 51117198904 | $18.13 | Shop at ECS Tuning | ||||
| For vehicles with National version japan or Control of number-plate attachment |
L807A=Yes S992A=Yes |
|||||||||
| 08 | Licence plate holder with threaded plug | US/JAP | 1 | 51117143749 | $17.58 | Shop at ECS Tuning | ||||
| 09 | Flap, towing eye, primed | 1 | 51117207299 | $11.39 | Shop at ECS Tuning | |||||
| When ordering indicate color code | ||||||||||
| 09 | Flap, towing eye, painted | CODE - UNI/MET. | 1 | 51110036841 | ENDED | Shop at ECS Tuning | ||||
| 10 | Support fender left | 1 | 51117058447 | $5.28 | Shop at ECS Tuning | |||||
| 10 | Support fender right | 1 | 51117058448 | $5.28 | Shop at ECS Tuning | |||||
| 11 | Insert, bumper front left | 1 | 51117134097 | $5.25 | Shop at ECS Tuning | |||||
| 11 | Insert, bumper front right | 1 | 51117134098 | $5.25 | Shop at ECS Tuning | |||||
| 12 | Seal, engine bonnet, front | 2 | 51767143757 | $6.71 | Shop at ECS Tuning | |||||
| For vehicles with Park Distance Control (PDC) |
S508A=Yes |
|||||||||
| 13 | Set of mounts for PDC sensor, front | 1 | 51117213857 | $16.65 | Shop at ECS Tuning | |||||
| 14 | Hex head screw with washer | ST4,8X16MM | X | 07147129160 | $0.36 | Shop at ECS Tuning | ||||
| 15 | Fillister head screw | X | 07147118369 | $0.80 | Shop at ECS Tuning | |||||
| Support fog headlights |
||||||||||
| 16 | C-clip nut, self-locking | ST 4.8 -ZNS3 | 10 | 07146951655 | $0.20 | Shop at ECS Tuning | ||||
| 17 | Expanding rivet | 4 | 07146971349 | $0.26 | Shop at ECS Tuning | |||||
| 18 | Screw | SECHSKANT | 4 | 07143428231 | $0.36 | Shop at ECS Tuning | ||||
| 19 | Spacer sleeve | 4 | 51117071270 | $0.56 | Shop at ECS Tuning | |||||
| 20 | Torx bolt | ISA M6X18 SW | 4 | 07146959923 | $0.55 | Shop at ECS Tuning | ||||
| REGISTRATION PLATE MOUNTING | ||||||||||
| 21 | Phillips screw f plastic material | TS 5X13 | 4 | 07146959892 | $0.30 | Shop at ECS Tuning | ||||
| For vehicles with Control of number-plate attachment |
S992A=Yes |
|||||||||
| 21 | Phillips screw f plastic material | TS5X25-ZNNID-SW | 4 | 07146959925 | $0.29 | Shop at ECS Tuning | ||||
| REGISTRATION PLATE MOUNTING | ||||||||||
| 22 | Covering cap | WEISS | X | 51181813017 | $0.21 | Shop at ECS Tuning | ||||
| 22 | Covering cap | EUROPABLAU | X | 51187060798 | $0.21 | Shop at ECS Tuning | ||||
| 22 | Covering cap | GOLDGELB | X | 51188106919 | $0.21 | Shop at ECS Tuning | ||||
| 23 | Washer | 4-200 HV-ZNS3 | 4 | 07119904207 | Shop at ECS Tuning | |||||
| Repair solution REGISTRATION PLATE MOUNTING |
||||||||||
| 24 | Blind rivet nut, flat headed | M5 | 4 | 51138400227 | $2.77 | Shop at ECS Tuning | ||||
| 25 | Screw | M5X20 | 4 | 46612315376 | $0.60 | Shop at ECS Tuning | ||||
Notes
- ENDED = the part has been discontinued (no longer available).
