Mounting parts, roof antenna for BMW 3 Series F30 LCI 320d (2016)
This Mounting parts, roof antenna technical drawing provides a detailed breakdown of the assembly for the 3 Series F30 LCI 320d. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2016.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| For vehicles with Glass roof, electrical and Headlining anthracite |
S403A=Yes S775A=Yes |
|||||||||
| 01 | Seal for sunroof | ANTHRAZIT | 1 | 54108036477 | $30.80 | Shop at ECS Tuning | ||||
| For vehicles with Glass roof, electrical and Headlining anthracite and Fabric Move/anthracite or Fabric Move/amber or Fabric Track/anthracite/akzent-grau or Fabric Track/anthracite/akzent-rot or Stofff corner/anthrazit/Akzent grau or Stofff corner/anthrazit/Akzent rot or Cloth Hexagon/Alcantara/anthracite or Sensatec/black/Accent red or Sensatec/mocca or Sensatec/black or Leather Dakota/black/akzent-rot or Leather Dakota/everest-grau/akzent-schw. or Leather Dakota/korall-rot/akzent-schwarz or Leather Dakota/black/excl. seam or Leather "Dakota"/schwarz |
S403A=Yes S775A=No BDAT=Yes BDLI=Yes BEL1=Yes BEL2=Yes CCL1=Yes CCL2=Yes HAAT=Yes KCL3=Yes KCMY=Yes KCSW=Yes LCL3=Yes LCL4=Yes LCL5=Yes LCLZ=Yes LCSW=Yes |
|||||||||
| 01 | Seal for sunroof | EVERESTGRAU | 1 | 51447271405 | Shop at ECS Tuning | |||||
| For vehicles with Glass roof, electrical and Headlining anthracite and Fabric/Leather Breeze/anthracite or Fabric/Leather Breeze/oyster/oyster or Fabric/leather Breeze/oyster/black or Sensatec/veneto-beige or Sensatec/black or Sensatec/veneto-beige or Leather "Dakota/veneto-beige" or Leather 'Dakota' sattelbraun/br. accents or Leather 'Dakota' sattelbraun/br. accents or Leather 'Dakota' venetobeige/oyster acc. or Leath.Dakota/veneto-beige/accent oyster or Leather Dakota/black/Accent oyster dark or Leather Dakota/oyster/Accent oyster dark or Leather Dakota/sattel-braun/excl. seam or Leather Dakota/veneto-beige/excl. seam or Leather Dakota/oyster/Accent oyster dark or Leather Dakota/cognac/accent brown or Leather Dakota/cognac/accent brown or Leather 'Dakota' venetobeige black |
S403A=Yes S775A=No CBAT=Yes CBDH=Yes CBOP=Yes KCDF=Yes KCSM=Yes KCV1=Yes LCDF=Yes LCDJ=Yes LCDY=Yes LCFJ=Yes LCFL=Yes LCL8=Yes LCL9=Yes LCLX=Yes LCLY=Yes LCOM=Yes LCRY=Yes LCRZ=Yes LCV1=Yes |
|||||||||
| 01 | Seal for sunroof | OYSTER | 1 | 51447271396 | Shop at ECS Tuning | |||||
| For vehicles with Glass roof, electrical and Headlining anthracite |
S403A=Yes S775A=Yes |
|||||||||
| 02 | Cover, microphone | SCHWARZ | 2 | 51448047526 | Shop at ECS Tuning | |||||
| For vehicles with Glass roof, electrical and Headlining anthracite and Fabric Move/anthracite or Fabric Move/amber or Fabric Track/anthracite/akzent-grau or Fabric Track/anthracite/akzent-rot or Stofff corner/anthrazit/Akzent grau or Stofff corner/anthrazit/Akzent rot or Cloth Hexagon/Alcantara/anthracite or Sensatec/black/Accent red or Sensatec/mocca or Sensatec/black or Leather Dakota/black/akzent-rot or Leather Dakota/everest-grau/akzent-schw. or Leather Dakota/korall-rot/akzent-schwarz or Leather Dakota/black/excl. seam or Leather "Dakota"/schwarz |
S403A=Yes S775A=No BDAT=Yes BDLI=Yes BEL1=Yes BEL2=Yes CCL1=Yes CCL2=Yes HAAT=Yes KCL3=Yes KCMY=Yes KCSW=Yes LCL3=Yes LCL4=Yes LCL5=Yes LCLZ=Yes LCSW=Yes |
|||||||||
| 02 | Cover, microphone | EVERESTGRAU | 2 | 51447230894 | Shop at ECS Tuning | |||||
| For vehicles with Glass roof, electrical and Headlining anthracite and Fabric/Leather Breeze/anthracite or Fabric/Leather Breeze/oyster/oyster or Fabric/leather Breeze/oyster/black or Sensatec/veneto-beige or Sensatec/black or Sensatec/veneto-beige or Leather "Dakota/veneto-beige" or Leather 'Dakota' sattelbraun/br. accents or Leather 'Dakota' sattelbraun/br. accents or Leather 'Dakota' venetobeige/oyster acc. or Leath.Dakota/veneto-beige/accent oyster or Leather Dakota/black/Accent oyster dark or Leather Dakota/oyster/Accent oyster dark or Leather Dakota/sattel-braun/excl. seam or Leather Dakota/veneto-beige/excl. seam or Leather Dakota/oyster/Accent oyster dark or Leather Dakota/cognac/accent brown or Leather Dakota/cognac/accent brown or Leather 'Dakota' venetobeige black |
S403A=Yes S775A=No CBAT=Yes CBDH=Yes CBOP=Yes KCDF=Yes KCSM=Yes KCV1=Yes LCDF=Yes LCDJ=Yes LCDY=Yes LCFJ=Yes LCFL=Yes LCL8=Yes LCL9=Yes LCLX=Yes LCLY=Yes LCOM=Yes LCRY=Yes LCRZ=Yes LCV1=Yes |
|||||||||
| 02 | Cover, microphone | OYSTER | 2 | 51447230893 | Shop at ECS Tuning | |||||
| For vehicles with Headlining anthracite |
S775A=Yes |
|||||||||
| 03 | Grab handle, front | SCHWARZ | 2 | 51167464443 | Shop at ECS Tuning | |||||
| For vehicles with Headlining anthracite and Fabric Move/anthracite or Fabric Move/amber or Fabric Track/anthracite/akzent-grau or Fabric Track/anthracite/akzent-rot or Stofff corner/anthrazit/Akzent grau or Stofff corner/anthrazit/Akzent rot or Cloth Hexagon/Alcantara/anthracite or Sensatec/black/Accent red or Sensatec/mocca or Sensatec/black or Leather Dakota/black/akzent-rot or Leather Dakota/everest-grau/akzent-schw. or Leather Dakota/korall-rot/akzent-schwarz or Leather Dakota/black/excl. seam or Leather "Dakota"/schwarz |
S775A=No BDAT=Yes BDLI=Yes BEL1=Yes BEL2=Yes CCL1=Yes CCL2=Yes HAAT=Yes KCL3=Yes KCMY=Yes KCSW=Yes LCL3=Yes LCL4=Yes LCL5=Yes LCLZ=Yes LCSW=Yes |
|||||||||
| 03 | Grab handle, front | EVERESTGRAU | 2 | 51167495617 | Shop at ECS Tuning | |||||
| For vehicles with Headlining anthracite and Fabric/Leather Breeze/anthracite or Fabric/Leather Breeze/oyster/oyster or Fabric/leather Breeze/oyster/black or Sensatec/veneto-beige or Sensatec/black or Sensatec/veneto-beige or Leather "Dakota/veneto-beige" or Leather 'Dakota' sattelbraun/br. accents or Leather 'Dakota' sattelbraun/br. accents or Leather 'Dakota' venetobeige/oyster acc. or Leath.Dakota/veneto-beige/accent oyster or Leather Dakota/black/Accent oyster dark or Leather Dakota/oyster/Accent oyster dark or Leather Dakota/sattel-braun/excl. seam or Leather Dakota/veneto-beige/excl. seam or Leather Dakota/oyster/Accent oyster dark or Leather Dakota/cognac/accent brown or Leather Dakota/cognac/accent brown or Leather 'Dakota' venetobeige black |
S775A=No CBAT=Yes CBDH=Yes CBOP=Yes KCDF=Yes KCSM=Yes KCV1=Yes LCDF=Yes LCDJ=Yes LCDY=Yes LCFJ=Yes LCFL=Yes LCL8=Yes LCL9=Yes LCLX=Yes LCLY=Yes LCOM=Yes LCRY=Yes LCRZ=Yes LCV1=Yes |
|||||||||
| 03 | Grab handle, front | OYSTER | 2 | 51167499074 | Shop at ECS Tuning | |||||
| For vehicles with Headlining anthracite |
S775A=Yes |
|||||||||
| 04 | Handle rear left | ANTHRAZIT | 1 | 51167464441 | Shop at ECS Tuning | |||||
| 04 | Handle rear right | ANTHRAZIT | 1 | 51167464442 | Shop at ECS Tuning | |||||
| For vehicles with Headlining anthracite and Fabric Move/anthracite or Fabric Move/amber or Fabric Track/anthracite/akzent-grau or Fabric Track/anthracite/akzent-rot or Stofff corner/anthrazit/Akzent grau or Stofff corner/anthrazit/Akzent rot or Cloth Hexagon/Alcantara/anthracite or Sensatec/black/Accent red or Sensatec/mocca or Sensatec/black or Leather Dakota/black/akzent-rot or Leather Dakota/everest-grau/akzent-schw. or Leather Dakota/korall-rot/akzent-schwarz or Leather Dakota/black/excl. seam or Leather "Dakota"/schwarz |
S775A=No BDAT=Yes BDLI=Yes BEL1=Yes BEL2=Yes CCL1=Yes CCL2=Yes HAAT=Yes KCL3=Yes KCMY=Yes KCSW=Yes LCL3=Yes LCL4=Yes LCL5=Yes LCLZ=Yes LCSW=Yes |
|||||||||
| 04 | Handle rear left | EVERESTGRAU | 1 | 51167495615 | Shop at ECS Tuning | |||||
| 04 | Handle rear right | EVERESTGRAU | 1 | 51167495616 | Shop at ECS Tuning | |||||
| For vehicles with Headlining anthracite and Fabric/Leather Breeze/anthracite or Fabric/Leather Breeze/oyster/oyster or Fabric/leather Breeze/oyster/black or Sensatec/veneto-beige or Sensatec/black or Sensatec/veneto-beige or Leather "Dakota/veneto-beige" or Leather 'Dakota' sattelbraun/br. accents or Leather 'Dakota' sattelbraun/br. accents or Leather 'Dakota' venetobeige/oyster acc. or Leath.Dakota/veneto-beige/accent oyster or Leather Dakota/black/Accent oyster dark or Leather Dakota/oyster/Accent oyster dark or Leather Dakota/sattel-braun/excl. seam or Leather Dakota/veneto-beige/excl. seam or Leather Dakota/oyster/Accent oyster dark or Leather Dakota/cognac/accent brown or Leather Dakota/cognac/accent brown or Leather 'Dakota' venetobeige black |
S775A=No CBAT=Yes CBDH=Yes CBOP=Yes KCDF=Yes KCSM=Yes KCV1=Yes LCDF=Yes LCDJ=Yes LCDY=Yes LCFJ=Yes LCFL=Yes LCL8=Yes LCL9=Yes LCLX=Yes LCLY=Yes LCOM=Yes LCRY=Yes LCRZ=Yes LCV1=Yes |
|||||||||
| 04 | Handle rear left | OYSTER | 1 | 51167499075 | Shop at ECS Tuning | |||||
| 04 | Handle rear right | OYSTER | 1 | 51167499076 | Shop at ECS Tuning | |||||
| 05 | Bracket, front left grab handle | 1 | 51167221007 | Shop at ECS Tuning | ||||||
| 05 | Bracket, front right grab handle | 1 | 51167221008 | Shop at ECS Tuning | ||||||
| 06 | Grab handle bracket, rear left | 1 | 51167221009 | Shop at ECS Tuning | ||||||
| 06 | Grab handle bracket, rear right | 1 | 51167221010 | Shop at ECS Tuning | ||||||
| 07 | Blind rivet | 14 | 07147265827 | Shop at ECS Tuning | ||||||
| 08 | Clip Natur | 4 | 51437001491 | $0.42 | Shop at ECS Tuning | |||||
| 09 | Hook and loop clip | 1 | 51447284007 | Shop at ECS Tuning | ||||||
| For vehicles with Glass roof, electrical |
S403A=Yes |
|||||||||
| 10 | Clip | 1 | 07147328846 | Shop at ECS Tuning | ||||||
