Exterior trim / grill for BMW 4 Series F36 Gran Coupé 418d (2015)
This Exterior trim / grill technical drawing provides a detailed breakdown of the assembly for the 4 Series F36 Gran Coupé 418d. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2015.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| For vehicles with Sport Line or M Aerodynamics package |
P7ACA=Yes S715A=Yes |
|||||||||
| 01 | Grille, front, left | SPORT | 1 | 03/2019 | 51135A3D025 | Shop at ECS Tuning | ||||
| 01 | Grille, front, right | SPORT | 1 | 03/2019 | 51135A3D026 | Shop at ECS Tuning | ||||
| For vehicles with Sport Line and Modern Line and Luxury Line and M Aerodynamics package |
P7ACA=No P7S1A=No P7S2A=No S715A=No |
|||||||||
| 01 | Grille, front, left | BASIS | 1 | 03/2021 | 51137294813 | ENDED | Shop at ECS Tuning | |||
| 01 | Grille, front, left | BASIS | 1 | 51135A3D021 | Shop at ECS Tuning | |||||
| 01 | Grille, front, right | BASIS | 1 | 51135A3D022 | Shop at ECS Tuning | |||||
| For vehicles with Sport Line and Modern Line and Luxury Line and M Aerodynamics package |
P7ACA=No P7S1A=No P7S2A=Yes S715A=No |
|||||||||
| 01 | Grille, front, left | LUXURY | 1 | 51135A3D023 | Shop at ECS Tuning | |||||
| 01 | Grille, front, right | LUXURY | 1 | 51135A3D024 | Shop at ECS Tuning | |||||
| For vehicles with Sport Line and Modern Line and Luxury Line and M Aerodynamics package |
P7ACA=No P7S1A=Yes P7S2A=No S715A=No |
|||||||||
| 01 | Grille, front, left | MODERN | 1 | 51135A4F1F7 | Shop at ECS Tuning | |||||
| 01 | Grille, front, right | MODERN | 1 | 51135A4F1F8 | Shop at ECS Tuning | |||||
| 01 | Grille, front, left | MODERN | 1 | 51137294819 | Shop at ECS Tuning | |||||
| 01 | Grille, front, right | MODERN | 1 | 51137294820 | Shop at ECS Tuning | |||||
| 02 | Roof molding prime-coated left | 1 | 51137372799 | Shop at ECS Tuning | ||||||
| 02 | Roof molding prime-coated right | 1 | 51137372800 | Shop at ECS Tuning | ||||||
| 03 | Clip | 8 | 51137291271 | Shop at ECS Tuning | ||||||
| Important! Color code PuMA measure 56903541 |
||||||||||
| 05 | Side panel air duct, primed, fr. left | 1 | 51747381993 | Shop at ECS Tuning | ||||||
| 05 | Side panel air duct, primed, fr. right | 1 | 51747381994 | Shop at ECS Tuning | ||||||
| For vehicles with Luxury Line and Exterior parts in vehicle color and High gloss shadow line Important! Color code PuMA measure 56903541 |
P7S2A=Yes S321A=No S760A=No |
|||||||||
| 05 | Air duct, lateral, left | CHROM | 1 | 51747294825 | Shop at ECS Tuning | |||||
| 05 | Air duct, lateral, right | CHROM | 1 | 51747294826 | Shop at ECS Tuning | |||||
| 06 | Clip | 6 | 07147130112 | Shop at ECS Tuning | ||||||
| 07 | Air duct, left | 1 | 51747294821 | Shop at ECS Tuning | ||||||
| 07 | Air duct, right | 1 | 51747294822 | Shop at ECS Tuning | ||||||
| 08 | Expanding rivet | L = 11MM | 8 | 07149807127 | Shop at ECS Tuning | |||||
| 09 | Blind compression rivet | 4 | 07147378241 | Shop at ECS Tuning | ||||||
Notes
- ENDED = the part has been discontinued (no longer available).
