Mounting parts, roof antenna for BMW 5 Series F10 LCI 520d (2016)
This Mounting parts, roof antenna technical drawing provides a detailed breakdown of the assembly for the 5 Series F10 LCI 520d. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2016.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| For vehicles with Headlining anthracite or Headliner in Alcantara anthracite |
S775A=Yes S776A=Yes |
|||||||||
| 01 | Cover, microphone | SCHWARZ | 2 | 51448047526 | Shop at ECS Tuning | |||||
| For vehicles with Headlining anthracite and Headliner in Alcantara anthracite and Fabric "Diagonal/anthracite" or Imitation leather "Leatherette/black" or Leather Dakota/black/excl. seam or Leather "Dakota"/schwarz or Leather Nappa/black/Exclusive seam |
S775A=No S776A=No AWAT=Yes K8SW=Yes LCLZ=Yes LCSW=Yes LZLZ=Yes |
|||||||||
| 01 | Cover, microphone | EVERESTGRAU | 2 | 51447230894 | Shop at ECS Tuning | |||||
| For vehicles with Headlining anthracite and Headliner in Alcantara anthracite and elfenbein-weiss/oyster Exclusive seam or elfenbein-weiss/oyster Exclusive seam or elfenbein-weiss/oyster Exclusive seam or anthracite or oyster Exclusive seam or oyster Exclusive seam or Black Exclusive seam or Fabric "diagonal/veneto-beige" or Imit. leather "Leatherette/veneto-beige" or Leatherette venetobeige black or Leather "Dakota/veneto-beige" or Leather "Dakota/zimt-braun" or Leather Dakota/veneto-beige/excl. seam or Leather Dakota/oyster/Exclusive seam or Leather 'Dakota' venetobeige black or Leathr 'Dakota' venetobeige blk ext seam or Lthr Nappa/elfenbein-weiss/Exclusiv seam or Leather Nappa/mocca/Exclusive seam |
S775A=No S776A=No EO=Yes ET=Yes EU=Yes IZ=Yes OT=Yes OU=Yes SJ=Yes AWDF=Yes K8DF=Yes K8V1=Yes LCDF=Yes LCEZ=Yes LCLY=Yes LCOX=Yes LCV1=Yes LCV2=Yes LZET=Yes LZMW=Yes |
|||||||||
| 01 | Cover, microphone | OYSTER | 2 | 51447230893 | Shop at ECS Tuning | |||||
| For vehicles with Glass roof, electrical and Headlining anthracite and Headliner in Alcantara anthracite |
S403A=Yes S775A=Yes S776A=Yes |
|||||||||
| 02 | Grab handle, front | SCHWARZ | 2 | 51168052676 | Shop at ECS Tuning | |||||
| For vehicles with Glass roof, electrical and Headlining anthracite and Headliner in Alcantara anthracite |
S403A=Yes S775A=Yes S776A=No |
|||||||||
| 02 | Grab handle, front | SCHWARZ | 2 | 51168052676 | Shop at ECS Tuning | |||||
| For vehicles with Glass roof, electrical and Headlining anthracite and Headliner in Alcantara anthracite |
S403A=Yes S775A=No S776A=Yes |
|||||||||
| 02 | Grab handle, front | SCHWARZ | 2 | 51168052676 | Shop at ECS Tuning | |||||
| For vehicles with Glass roof, electrical and Headlining anthracite and Headliner in Alcantara anthracite |
S403A=No S775A=Yes S776A=Yes |
|||||||||
| 02 | Grab handle, front | SCHWARZ | 2 | 51167464443 | Shop at ECS Tuning | |||||
| For vehicles with Glass roof, electrical and Headlining anthracite and Headliner in Alcantara anthracite |
S403A=No S775A=Yes S776A=No |
|||||||||
| 02 | Grab handle, front | SCHWARZ | 2 | 51167464443 | Shop at ECS Tuning | |||||
| For vehicles with Glass roof, electrical and Headlining anthracite and Headliner in Alcantara anthracite |
S403A=No S775A=No S776A=Yes |
|||||||||
| 02 | Grab handle, front | SCHWARZ | 2 | 51167464443 | Shop at ECS Tuning | |||||
| For vehicles with Glass roof, electrical and Headlining anthracite and Headliner in Alcantara anthracite and Fabric "Diagonal/anthracite" or Imitation leather "Leatherette/black" or Leather Dakota/black/excl. seam or Leather "Dakota"/schwarz or Leather Nappa/black/Exclusive seam |
S403A=Yes S775A=No S776A=No AWAT=Yes K8SW=Yes LCLZ=Yes LCSW=Yes LZLZ=Yes |
|||||||||
| 02 | Grab handle, front | EVERESTGRAU | 2 | 51167290029 | Shop at ECS Tuning | |||||
| For vehicles with Glass roof, electrical and Headlining anthracite and Headliner in Alcantara anthracite and Fabric "Diagonal/anthracite" or Imitation leather "Leatherette/black" or Leather Dakota/black/excl. seam or Leather "Dakota"/schwarz or Leather Nappa/black/Exclusive seam |
S403A=No S775A=No S776A=No AWAT=Yes K8SW=Yes LCLZ=Yes LCSW=Yes LZLZ=Yes |
|||||||||
| 02 | Grab handle, front | EVERESTGRAU | 2 | 51167495617 | Shop at ECS Tuning | |||||
| For vehicles with Glass roof, electrical and Headlining anthracite and Headliner in Alcantara anthracite and elfenbein-weiss/oyster Exclusive seam or elfenbein-weiss/oyster Exclusive seam or elfenbein-weiss/oyster Exclusive seam or anthracite or oyster Exclusive seam or oyster Exclusive seam or Black Exclusive seam or Fabric "diagonal/veneto-beige" or Imit. leather "Leatherette/veneto-beige" or Leatherette venetobeige black or Leather "Dakota/veneto-beige" or Leather "Dakota/zimt-braun" or Leather Dakota/veneto-beige/excl. seam or Leather Dakota/oyster/Exclusive seam or Leather 'Dakota' venetobeige black or Leathr 'Dakota' venetobeige blk ext seam or Lthr Nappa/elfenbein-weiss/Exclusiv seam or Leather Nappa/mocca/Exclusive seam |
S403A=No S775A=No S776A=No EO=Yes ET=Yes EU=Yes IZ=Yes OT=Yes OU=Yes SJ=Yes AWDF=Yes K8DF=Yes K8V1=Yes LCDF=Yes LCEZ=Yes LCLY=Yes LCOX=Yes LCV1=Yes LCV2=Yes LZET=Yes LZMW=Yes |
|||||||||
| 02 | Grab handle, front | OYSTER | 2 | 51167499074 | Shop at ECS Tuning | |||||
| For vehicles with Glass roof, electrical and Headlining anthracite and Headliner in Alcantara anthracite and elfenbein-weiss/oyster Exclusive seam or elfenbein-weiss/oyster Exclusive seam or elfenbein-weiss/oyster Exclusive seam or anthracite or oyster Exclusive seam or oyster Exclusive seam or Black Exclusive seam or Fabric "diagonal/veneto-beige" or Imit. leather "Leatherette/veneto-beige" or Leatherette venetobeige black or Leather "Dakota/veneto-beige" or Leather "Dakota/zimt-braun" or Leather Dakota/veneto-beige/excl. seam or Leather Dakota/oyster/Exclusive seam or Leather 'Dakota' venetobeige black or Leathr 'Dakota' venetobeige blk ext seam or Lthr Nappa/elfenbein-weiss/Exclusiv seam or Leather Nappa/mocca/Exclusive seam |
S403A=Yes S775A=No S776A=No EO=Yes ET=Yes EU=Yes IZ=Yes OT=Yes OU=Yes SJ=Yes AWDF=Yes K8DF=Yes K8V1=Yes LCDF=Yes LCEZ=Yes LCLY=Yes LCOX=Yes LCV1=Yes LCV2=Yes LZET=Yes LZMW=Yes |
|||||||||
| 02 | Grab handle, front | OYSTER | 2 | 51167290030 | Shop at ECS Tuning | |||||
| For vehicles with Glass roof, electrical and Headlining anthracite and Headliner in Alcantara anthracite |
S403A=Yes S775A=Yes S776A=Yes |
|||||||||
| 03 | Handle rear left | SCHWARZ | 1 | 51168052689 | +core | Shop at ECS Tuning | ||||
| 03 | Handle rear right | SCHWARZ | 1 | 51168052690 | +core | Shop at ECS Tuning | ||||
| For vehicles with Glass roof, electrical and Headlining anthracite and Headliner in Alcantara anthracite |
S403A=Yes S775A=Yes S776A=No |
|||||||||
| 03 | Handle rear left | SCHWARZ | 1 | 51168052689 | +core | Shop at ECS Tuning | ||||
| 03 | Handle rear right | SCHWARZ | 1 | 51168052690 | +core | Shop at ECS Tuning | ||||
| For vehicles with Glass roof, electrical and Headlining anthracite and Headliner in Alcantara anthracite |
S403A=Yes S775A=No S776A=Yes |
|||||||||
| 03 | Handle rear left | SCHWARZ | 1 | 51168052689 | +core | Shop at ECS Tuning | ||||
| 03 | Handle rear right | SCHWARZ | 1 | 51168052690 | +core | Shop at ECS Tuning | ||||
| For vehicles with Glass roof, electrical and Headlining anthracite and Headliner in Alcantara anthracite |
S403A=No S775A=Yes S776A=Yes |
|||||||||
| 03 | Handle rear left | ANTHRAZIT | 1 | 51167464441 | Shop at ECS Tuning | |||||
| 03 | Handle rear right | ANTHRAZIT | 1 | 51167464442 | Shop at ECS Tuning | |||||
| For vehicles with Glass roof, electrical and Headlining anthracite and Headliner in Alcantara anthracite |
S403A=No S775A=Yes S776A=No |
|||||||||
| 03 | Handle rear left | ANTHRAZIT | 1 | 51167464441 | Shop at ECS Tuning | |||||
| 03 | Handle rear right | ANTHRAZIT | 1 | 51167464442 | Shop at ECS Tuning | |||||
| For vehicles with Glass roof, electrical and Headlining anthracite and Headliner in Alcantara anthracite |
S403A=No S775A=No S776A=Yes |
|||||||||
| 03 | Handle rear left | ANTHRAZIT | 1 | 51167464441 | Shop at ECS Tuning | |||||
| 03 | Handle rear right | ANTHRAZIT | 1 | 51167464442 | Shop at ECS Tuning | |||||
| For vehicles with Glass roof, electrical and Headlining anthracite and Headliner in Alcantara anthracite and Fabric "Diagonal/anthracite" or Imitation leather "Leatherette/black" or Leather Dakota/black/excl. seam or Leather "Dakota"/schwarz or Leather Nappa/black/Exclusive seam |
S403A=Yes S775A=No S776A=No AWAT=Yes K8SW=Yes LCLZ=Yes LCSW=Yes LZLZ=Yes |
|||||||||
| 03 | Handle rear left | EVERESTGRAU | 1 | 51167300413 | +core | Shop at ECS Tuning | ||||
| 03 | Handle rear right | EVERESTGRAU | 1 | 51167300414 | +core | Shop at ECS Tuning | ||||
| For vehicles with Glass roof, electrical and Headlining anthracite and Headliner in Alcantara anthracite and Fabric "Diagonal/anthracite" or Imitation leather "Leatherette/black" or Leather Dakota/black/excl. seam or Leather "Dakota"/schwarz or Leather Nappa/black/Exclusive seam |
S403A=No S775A=No S776A=No AWAT=Yes K8SW=Yes LCLZ=Yes LCSW=Yes LZLZ=Yes |
|||||||||
| 03 | Handle rear left | EVERESTGRAU | 1 | 51167495615 | Shop at ECS Tuning | |||||
| 03 | Handle rear right | EVERESTGRAU | 1 | 51167495616 | Shop at ECS Tuning | |||||
| For vehicles with Glass roof, electrical and Headlining anthracite and Headliner in Alcantara anthracite and Veneto-beige or elfenbein-weiss/oyster Exclusive seam or elfenbein-weiss/oyster Exclusive seam or elfenbein-weiss/oyster Exclusive seam or zimt-braun or anthracite or Veneto beige exclusive seam or Mocha or oyster Exclusive seam or oyster Exclusive seam or oyster Exclusive seam or Black Exclusive seam |
S403A=Yes S775A=No S776A=No DF=Yes EO=Yes ET=Yes EU=Yes EZ=Yes IZ=Yes LY=Yes MW=Yes OT=Yes OU=Yes OX=Yes SJ=Yes |
|||||||||
| 03 | Handle rear left | OYSTER | 1 | 51167300415 | +core | Shop at ECS Tuning | ||||
| 03 | Handle rear right | OYSTER | 1 | 51167300416 | +core | Shop at ECS Tuning | ||||
| For vehicles with Glass roof, electrical and Headlining anthracite and Headliner in Alcantara anthracite and elfenbein-weiss/oyster Exclusive seam or elfenbein-weiss/oyster Exclusive seam or elfenbein-weiss/oyster Exclusive seam or anthracite or oyster Exclusive seam or oyster Exclusive seam or Black Exclusive seam or Fabric "diagonal/veneto-beige" or Imit. leather "Leatherette/veneto-beige" or Leatherette venetobeige black or Leather "Dakota/veneto-beige" or Leather "Dakota/zimt-braun" or Leather Dakota/veneto-beige/excl. seam or Leather Dakota/oyster/Exclusive seam or Leather 'Dakota' venetobeige black or Leathr 'Dakota' venetobeige blk ext seam or Lthr Nappa/elfenbein-weiss/Exclusiv seam or Leather Nappa/mocca/Exclusive seam |
S403A=No S775A=No S776A=No EO=Yes ET=Yes EU=Yes IZ=Yes OT=Yes OU=Yes SJ=Yes AWDF=Yes K8DF=Yes K8V1=Yes LCDF=Yes LCEZ=Yes LCLY=Yes LCOX=Yes LCV1=Yes LCV2=Yes LZET=Yes LZMW=Yes |
|||||||||
| 03 | Handle rear left | OYSTER | 1 | 51167499075 | Shop at ECS Tuning | |||||
| 03 | Handle rear right | OYSTER | 1 | 51167499076 | Shop at ECS Tuning | |||||
| 04 | Bracket, front left grab handle | 1 | 51169117629 | Shop at ECS Tuning | ||||||
| 04 | Bracket, front right grab handle | 1 | 51169117630 | Shop at ECS Tuning | ||||||
| 05 | Grab handle bracket, rear left | 1 | 51169117633 | Shop at ECS Tuning | ||||||
| 05 | Grab handle bracket, rear right | 1 | 51169117634 | Shop at ECS Tuning | ||||||
| 06 | Blind rivet | 4,5 MM | 12 | 07146984985 | $0.28 | Shop at ECS Tuning | ||||
| For vehicles with Headlining anthracite and Headliner in Alcantara anthracite |
S775A=No S776A=Yes |
|||||||||
| 07 | Cover, brake light, Alcantara | SCHWARZ | 1 | 51448038142 | Shop at ECS Tuning | |||||
| For vehicles with Headlining anthracite and Headliner in Alcantara anthracite |
S775A=Yes S776A=No |
|||||||||
| 07 | Cover, stop lamp | ANTHRAZIT | 1 | 51448038182 | +core | Shop at ECS Tuning | ||||
| For vehicles with Headlining anthracite and Headliner in Alcantara anthracite and Fabric "Diagonal/anthracite" or Imitation leather "Leatherette/black" or Leather Dakota/black/excl. seam or Leather "Dakota"/schwarz or Leather Nappa/black/Exclusive seam |
S775A=No S776A=No AWAT=Yes K8SW=Yes LCLZ=Yes LCSW=Yes LZLZ=Yes |
|||||||||
| 07 | Cover, stop lamp | EVERESTGRAU | 1 | 51449173446 | +core | Shop at ECS Tuning | ||||
| For vehicles with Headlining anthracite and Headliner in Alcantara anthracite and Veneto-beige or elfenbein-weiss/oyster Exclusive seam or elfenbein-weiss/oyster Exclusive seam or elfenbein-weiss/oyster Exclusive seam or zimt-braun or anthracite or Veneto beige exclusive seam or Mocha or oyster Exclusive seam or oyster Exclusive seam or oyster Exclusive seam or Black Exclusive seam |
S775A=No S776A=No DF=Yes EO=Yes ET=Yes EU=Yes EZ=Yes IZ=Yes LY=Yes MW=Yes OT=Yes OU=Yes OX=Yes SJ=Yes |
|||||||||
| 07 | Cover, stop lamp | OYSTER | 1 | 51449196977 | Shop at ECS Tuning | |||||
Notes
- +core = plus core charge (possibility of a return of the old part)
