Right TRUNK TRIM for BMW 5 Series F18 LCI 525Li (2017)
This Right TRUNK TRIM technical drawing provides a detailed breakdown of the assembly for the 5 Series F18 LCI 525Li. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2017.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| For vehicles with Motor extended operation circuit and Additional energy supply and Unmasked official vehicle and Patrol vehicle, camouflaged and Integral active steering |
S108A=No S146A=No S185A=No S186A=No S2VHA=No |
|||||||||
| 02 | Panel wheel housing part.trunk right | 1 | 51479163194 | Shop at ECS Tuning | ||||||
| For vehicles with Motor extended operation circuit and Additional energy supply and Unmasked official vehicle and Patrol vehicle, camouflaged and Integral active steering |
S108A=No S146A=No S185A=No S186A=No S2VHA=Yes |
|||||||||
| 03 | Panel wheel housing part.trunk right | 1 | 51477210938 | Shop at ECS Tuning | ||||||
| 05 | Cover, power distribution box | 1 | 51477260061 | +core | Shop at ECS Tuning | |||||
| 06 | Expanding rivet | D = 8MM | X | 51471911992 | $0.40 | Shop at ECS Tuning | ||||
| 07 | Hook | 1 | 51477258562 | Shop at ECS Tuning | ||||||
| 08 | Foam insert trunk, right | 1 | 51477247280 | Shop at ECS Tuning | ||||||
| 10 | Cover, fastening loop | 1 | 51477234944 | Shop at ECS Tuning | ||||||
| 11 | Tie-down ring | 1 | 51477129196 | $7.23 | Shop at ECS Tuning | |||||
| 12 | Socket head cap screw with shoulder | 1 | 51477130768 | $1.09 | Shop at ECS Tuning | |||||
Notes
- +core = plus core charge (possibility of a return of the old part)
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 5 Series F18 LCI 525Li Right TRUNK TRIM?
- This technical diagram illustrates the Right TRUNK TRIM within the Vehicle trim group for the 5 Series F18 LCI 525Li produced during 2017. It provides a detailed exploded view of the components, identifying key parts such as the Panel wheel housing part.trunk right (Part #51479163194).
- Which models use the hardware listed in this Right TRUNK TRIM?
- The hardware and components featured in the Right TRUNK TRIM are specific to the 5 Series F18 LCI 525Li produced during 2017. These technical specifications ensure that parts like the Panel wheel housing part.trunk right (51479163194) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Right TRUNK TRIM assembly?
- Each item in the Right TRUNK TRIM corresponds to the numbered list below the illustration. For the 5 Series F18 LCI 525Li, you can identify the Panel wheel housing part.trunk right by locating its position on the schematic, which then links to the official BMW part number 51479163194 for the Vehicle trim section.
