Mounting parts, roof antenna for BMW 4 Series F36 Gran Coupé 418d (2015)
This Mounting parts, roof antenna technical drawing provides a detailed breakdown of the assembly for the 4 Series F36 Gran Coupé 418d. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2015.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| For vehicles with Glass roof, electrical and Headlining anthracite |
S403A=Yes S775A=Yes |
|||||||||
| 01 | Seal for sunroof | ANTHRAZIT | 1 | 54108036477 | $30.80 | Shop at ECS Tuning | ||||
| For vehicles with Glass roof, electrical and Headlining anthracite and |
S403A=Yes S775A=No |
|||||||||
| 01 | Seal for sunroof | EVERESTGRAU | 1 | 51447271405 | Shop at ECS Tuning | |||||
| For vehicles with Glass roof, electrical and Headlining anthracite and Fabric/Leather Breeze/anthracite or Fabric/Leather Breeze/oyster/oyster or Fabric/leather Breeze/oyster/black or Sensatec/black or Sensatec/veneto-beige or Leather "Dakota/elfenbein-weiss" or Leath.Dakota/elfenbein-white/acc.oyster or Leather 'Dakota' venetobeige/oyster acc. or Leath.Dakota/veneto-beige/accent oyster or Leather Dakota/black/Accent oyster dark or Leather Dakota/oyster/Accent oyster dark or Leather Dakota/sattel-braun/excl. seam or Leather Dakota/veneto-beige/excl. seam or Leather Dakota / mocca or Leather Dakota/oyster/Accent oyster dark or Leather Dakota/cognac/accent brown or Leather Dakota/cognac/accent brown or Leather Dakota/nacht-blue/accent oyster |
S403A=Yes S775A=No CBAT=Yes CBDH=Yes CBOP=Yes KCSM=Yes KCV1=Yes LCEW=Yes LCFH=Yes LCFJ=Yes LCFL=Yes LCL8=Yes LCL9=Yes LCLX=Yes LCLY=Yes LCMY=Yes LCOM=Yes LCRY=Yes LCRZ=Yes LCTX=Yes |
|||||||||
| 01 | Seal for sunroof | OYSTER | 1 | 51447271396 | Shop at ECS Tuning | |||||
| For vehicles with Headlining anthracite |
S775A=Yes |
|||||||||
| 02 | Cover, microphone | SCHWARZ | 1 | 51448047526 | Shop at ECS Tuning | |||||
| For vehicles with Headlining anthracite and |
S775A=No |
|||||||||
| 02 | Cover, microphone | EVERESTGRAU | 1 | 51447230894 | Shop at ECS Tuning | |||||
| 02 | Cover, microphone | OYSTER | 1 | 51447230893 | Shop at ECS Tuning | |||||
| For vehicles with Headlining anthracite |
S775A=Yes |
|||||||||
| 03 | Cover, microphone | BLACK | 1 | 51447248224 | Shop at ECS Tuning | |||||
| For vehicles with Headlining anthracite and Fabric Move/anthracite or Fabric Track/anthracite/akzent-grau or Fabric Track/anthracite/akzent-rot or Sensatec/black/Accent red or Sensatec/black or Leather Dakota/black/akzent-rot or Leather Dakota/korall-rot/akzent-schwarz or Leather Dakota/black/excl. seam or Leather "Dakota"/schwarz |
S775A=No BDAT=Yes BEL1=Yes BEL2=Yes KCL3=Yes KCSW=Yes LCL3=Yes LCL5=Yes LCLZ=Yes LCSW=Yes |
|||||||||
| 03 | Cover, microphone | EVERESTGRAU | 1 | 51447230894 | Shop at ECS Tuning | |||||
| For vehicles with Headlining anthracite and Fabric/Leather Breeze/anthracite or Fabric/Leather Breeze/oyster/oyster or Fabric/leather Breeze/oyster/black or Sensatec/black or Leather "Dakota/elfenbein-weiss" or Leather Dakota/oyster/Accent oyster dark or Leather Dakota/sattel-braun/excl. seam or Leather Dakota/veneto-beige/excl. seam or Leather Dakota / mocca or Leather Dakota/oyster/Accent oyster dark |
S775A=No CBAT=Yes CBDH=Yes CBOP=Yes KCSM=Yes LCEW=Yes LCL9=Yes LCLX=Yes LCLY=Yes LCMY=Yes LCOM=Yes |
|||||||||
| 03 | Cover, microphone | OYSTER | 1 | 51447230893 | Shop at ECS Tuning | |||||
| 04 | Retainer, headliner, front left | 1 | 51167363619 | Shop at ECS Tuning | ||||||
| 04 | Retainer, headliner, front right | 1 | 51167363620 | Shop at ECS Tuning | ||||||
| 05 | Bracket clothing hook, left | 1 | 51167311209 | Shop at ECS Tuning | ||||||
| 05 | Bracket clothing hook, right | 1 | 51167311210 | Shop at ECS Tuning | ||||||
| For vehicles with Headlining anthracite |
S775A=Yes |
|||||||||
| 06 | Clothes hook | SCHWARZ | 2 | 51169150380 | $13.27 | Shop at ECS Tuning | ||||
| For vehicles with Headlining anthracite and |
S775A=No |
|||||||||
| 06 | Clothes hook | EVERESTGRAU | 2 | 51169232493 | +core | Shop at ECS Tuning | ||||
| 06 | Clothes hook | OYSTER | 2 | 51169232492 | +core | Shop at ECS Tuning | ||||
| 07 | Sheet-metal screw, black | ST4,8X19MM | 2 | 07119907854 | Shop at ECS Tuning | |||||
| 08 | Clip | 1 | 51437194187 | $1.98 | Shop at ECS Tuning | |||||
| 09 | Holder | 1 | 51438183314 | $0.82 | Shop at ECS Tuning | |||||
| 10 | Clip Natur | 2 | 51437001491 | $0.42 | Shop at ECS Tuning | |||||
Notes
- +core = plus core charge (possibility of a return of the old part)
