Trim cover, rear for BMW 3 Series G21 Touring LCI 320dX (2025)
This Trim cover, rear technical drawing provides a detailed breakdown of the assembly for the 3 Series G21 Touring LCI 320dX. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2025.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| i | For vehicles with M Aerodynamics package |
S715A=No |
||||||||
| For vehicles with Parking assistance system and Parking assistance system Plus |
S5DMA=Yes S5DNA=Yes |
|||||||||
| 01 | Bumper cover primed rear | PDC/PMA 2BORDIG | 1 | 51125A69644 | Shop at ECS Tuning | |||||
| For vehicles with Parking assistance system and Parking assistance system Plus |
S5DMA=Yes S5DNA=No |
|||||||||
| 01 | Bumper cover primed rear | PDC/PMA 2BORDIG | 1 | 51125A69644 | Shop at ECS Tuning | |||||
| For vehicles with Parking assistance system and Parking assistance system Plus |
S5DMA=No S5DNA=Yes |
|||||||||
| 01 | Bumper cover primed rear | PDC/PMA 2BORDIG | 1 | 51125A69644 | Shop at ECS Tuning | |||||
| For vehicles with Park Distance Control (PDC) and Parking assistance system and Parking assistance system Plus |
S508A=Yes S5DMA=No S5DNA=No |
|||||||||
| 01 | Bumper cover primed rear | PDC/ 2 BORDIG | 1 | 51125A69643 | Shop at ECS Tuning | |||||
| 02 | Cover, towing eye, primed, rear | 1 | 51125A697D6 | Shop at ECS Tuning | ||||||
| 03 | Bumper bracket side left | 1 | 51125A1CC65 | Shop at ECS Tuning | ||||||
| 03 | Bumper bracket side right | 1 | 51125A1CC66 | Shop at ECS Tuning | ||||||
| 04 | Mount for bumper, left rear center | 1 | 51125A1CC61 | Shop at ECS Tuning | ||||||
| 04 | Mount for bumper, right rear center | 1 | 51125A1CC62 | Shop at ECS Tuning | ||||||
| 05 | Adapter support | 1 | 51125A243E0 | Shop at ECS Tuning | ||||||
| For vehicles with Driving Assistant and Driving assistant professional |
S5ASA=Yes S5AUA=Yes |
|||||||||
| 06 | Absorber funnel, left | SRR | 1 | 51125A1CC63 | Shop at ECS Tuning | |||||
| 06 | Absorber funnel right | SRR | 1 | 51125A1CC64 | Shop at ECS Tuning | |||||
| For vehicles with Driving Assistant and Driving assistant professional |
S5ASA=Yes S5AUA=No |
|||||||||
| 06 | Absorber funnel, left | SRR | 1 | 51125A1CC63 | Shop at ECS Tuning | |||||
| 06 | Absorber funnel right | SRR | 1 | 51125A1CC64 | Shop at ECS Tuning | |||||
| For vehicles with Driving Assistant and Driving assistant professional |
S5ASA=No S5AUA=Yes |
|||||||||
| 06 | Absorber funnel, left | SRR | 1 | 51125A1CC63 | Shop at ECS Tuning | |||||
| 06 | Absorber funnel right | SRR | 1 | 51125A1CC64 | Shop at ECS Tuning | |||||
| For vehicles with Park Distance Control (PDC) and Parking assistance system and Parking assistance system Plus |
S508A=Yes S5DMA=Yes S5DNA=Yes |
|||||||||
| 07 | Kit mount PDC/PMA sensor | 1 | 51125A697C9 | Shop at ECS Tuning | ||||||
| For vehicles with Park Distance Control (PDC) and Parking assistance system and Parking assistance system Plus |
S508A=Yes S5DMA=Yes S5DNA=No |
|||||||||
| 07 | Kit mount PDC/PMA sensor | 1 | 51125A697C9 | Shop at ECS Tuning | ||||||
| For vehicles with Park Distance Control (PDC) and Parking assistance system and Parking assistance system Plus |
S508A=Yes S5DMA=No S5DNA=Yes |
|||||||||
| 07 | Kit mount PDC/PMA sensor | 1 | 51125A697C9 | Shop at ECS Tuning | ||||||
| For vehicles with Park Distance Control (PDC) and Parking assistance system and Parking assistance system Plus |
S508A=Yes S5DMA=No S5DNA=No |
|||||||||
| 07 | Kit mount PDC/PMA sensor | 1 | 51125A697C9 | Shop at ECS Tuning | ||||||
| For vehicles with Park Distance Control (PDC) and Parking assistance system and Parking assistance system Plus |
S508A=No S5DMA=Yes S5DNA=Yes |
|||||||||
| 07 | Kit mount PDC/PMA sensor | 1 | 51125A697C9 | Shop at ECS Tuning | ||||||
| For vehicles with Park Distance Control (PDC) and Parking assistance system and Parking assistance system Plus |
S508A=No S5DMA=Yes S5DNA=No |
|||||||||
| 07 | Kit mount PDC/PMA sensor | 1 | 51125A697C9 | Shop at ECS Tuning | ||||||
| For vehicles with Park Distance Control (PDC) and Parking assistance system and Parking assistance system Plus |
S508A=No S5DMA=No S5DNA=Yes |
|||||||||
| 07 | Kit mount PDC/PMA sensor | 1 | 51125A697C9 | Shop at ECS Tuning | ||||||
| For vehicles with Comfort access |
S322A=Yes |
|||||||||
| 08 | Bracket for antenna | COMFORT ACCESS | 1 | 51125A33E84 | Shop at ECS Tuning | |||||
| 09 | Combination nut | 19 | 07147305178 | Shop at ECS Tuning | ||||||
| 10 | Clip | M PDC | 4 | 61137849481 | Shop at ECS Tuning | |||||
| 11 | Fillister head screw | 2 | 07147118369 | $0.80 | Shop at ECS Tuning | |||||
| 12 | Expanding nut | ST 4.8 | 2 | 63121374075 | $0.23 | Shop at ECS Tuning | ||||
| 13 | Fillister head screw | ST5X17-ZNS3 | 2 | 07147127714 | $0.25 | Shop at ECS Tuning | ||||
