Door trim panel, front for BMW MINI Countryman F60 One (2020)
This Door trim panel, front technical drawing provides a detailed breakdown of the assembly for the MINI Countryman F60 One. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2020.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| For vehicles with Colour Line Satellite Grey and satellite-grey |
S4C3A=Yes GK=Yes |
|||||||||
| 01 | Door trim panel, front left | SATTELITE GREY | 1 | 51417476523 | NoS | Shop at ECS Tuning | ||||
| 01 | Door trim panel, front right | SATTELITE GREY | 1 | 51417476524 | NoS | Shop at ECS Tuning | ||||
| For vehicles with Color Line British Oak and British oak |
S4F1A=Yes M9=Yes |
|||||||||
| 01 | Door trim panel, front left | STONE HILL GREY | 1 | 51417476519 | Shop at ECS Tuning | |||||
| 01 | Door trim panel, front right | STONE HILL GREY | 1 | 51417476520 | NoS | Shop at ECS Tuning | ||||
| For vehicles with Color Line malt brown and malt-brown |
S4FQA=Yes MJ=Yes |
|||||||||
| 01 | Door trim panel, front left | MALT BROWN | 1 | 51417476515 | NoS | Shop at ECS Tuning | ||||
| 01 | Door trim panel, front right | MALT BROWN | 1 | 51417476516 | NoS | Shop at ECS Tuning | ||||
| For vehicles with Colour Line Satellite Grey and Color Line British Oak and Color Line malt brown and Fabric/leatherette in Black Pearl |
S4C3A=No S4F1A=No S4FQA=No KD=Yes |
|||||||||
| 01 | Door trim panel, front left | SHADOW GREY | 1 | 51417476503 | NoS | Shop at ECS Tuning | ||||
| 01 | Door trim panel, front right | SHADOW GREY | 1 | 51417476504 | NoS | Shop at ECS Tuning | ||||
| For vehicles with Colour Line Satellite Grey and Color Line British Oak and Color Line malt brown and MINI Yours Leather Lounge |
S4C3A=No S4F1A=No S4FQA=No TY=Yes |
|||||||||
| 01 | Door trim panel, front left | CARBON BLACK | 1 | 51417476527 | Shop at ECS Tuning | |||||
| 01 | Door trim panel, front right | CARBON BLACK | 1 | 51417476528 | NoS | Shop at ECS Tuning | ||||
| For vehicles with Colour Line Satellite Grey and Color Line British Oak and Color Line malt brown and Cloth/leather cord |
S4C3A=No S4F1A=No S4FQA=No CX=Yes |
|||||||||
| 01 | Door trim panel, front left | CARBON BLACK | 1 | 51417476507 | NoS | Shop at ECS Tuning | ||||
| 01 | Door trim panel, front right | CARBON BLACK | 1 | 51417476508 | NoS | Shop at ECS Tuning | ||||
| For vehicles with Colour Line Satellite Grey and Color Line British Oak and Color Line malt brown and Dinamica/leather |
S4C3A=No S4F1A=No S4FQA=No GS=Yes |
|||||||||
| 01 | Door trim panel, front left | CHILLI RED | 1 | 51417476531 | NoS | Shop at ECS Tuning | ||||
| 01 | Door trim panel, front right | CHILLI RED | 1 | 51417476532 | NoS | Shop at ECS Tuning | ||||
| For vehicles with Colour Line Satellite Grey and Color Line British Oak and Color Line malt brown and FABRIC FIREWORK or FABRIC DOUBLE STRIPE or Imitation leather "Leatherette" |
S4C3A=No S4F1A=No S4FQA=No BG=Yes BZ=Yes K9=Yes |
|||||||||
| 01 | Door trim panel, front left | CARBON BLACK | 1 | 51417476499 | Shop at ECS Tuning | |||||
| 01 | Door trim panel, front right | CARBON BLACK | 1 | 51417476500 | Shop at ECS Tuning | |||||
| For vehicles with Colour Line Satellite Grey and Color Line British Oak and Color Line malt brown and Leder cross punch or Leather 'Chester' or Leather "Lounge" |
S4C3A=No S4F1A=No S4FQA=No NE=Yes NY=Yes T9=Yes |
|||||||||
| 01 | Door trim panel, front left | CARBON BLACK | 1 | 51417476511 | NoS | Shop at ECS Tuning | ||||
| 01 | Door trim panel, front right | CARBON BLACK | 1 | 51417476512 | NoS | Shop at ECS Tuning | ||||
| For vehicles with Interior surface Piano Black and Color Line malt brown and MINI Yours Interior Style Chestnut and MINI Yours Interior Style British Oak and MINI Yours Interior Style Piano Black and malt-brown |
S4BDA=Yes S4FQA=Yes S4G5A=Yes S4G6A=Yes S4GVA=Yes MJ=Yes |
|||||||||
| 01 | Door trim panel, front left | MALT BROWN | 1 | 51417476517 | NoS | Shop at ECS Tuning | ||||
| 01 | Door trim panel, front right | MALT BROWN | 1 | 51417476518 | NoS | Shop at ECS Tuning | ||||
| For vehicles with Interior surface Piano Black and Color Line British Oak and MINI Yours Interior Style Chestnut and MINI Yours Interior Style British Oak and MINI Yours Interior Style Piano Black and British oak |
S4BDA=Yes S4F1A=Yes S4G5A=Yes S4G6A=Yes S4GVA=Yes M9=Yes |
|||||||||
| 01 | Door trim panel, front left | STONE HILL GREY | 1 | 51417476521 | Shop at ECS Tuning | |||||
| 01 | Door trim panel, front right | STONE HILL GREY | 1 | 51417476522 | Shop at ECS Tuning | |||||
| For vehicles with Interior surface Piano Black and Colour Line Satellite Grey and MINI Yours Interior Style Chestnut and MINI Yours Interior Style British Oak and MINI Yours Interior Style Piano Black and satellite-grey |
S4BDA=Yes S4C3A=Yes S4G5A=Yes S4G6A=Yes S4GVA=Yes GK=Yes |
|||||||||
| 01 | Door trim panel, front left | SATELLITE GREY | 1 | 51417476525 | NoS | Shop at ECS Tuning | ||||
| 01 | Door trim panel, front right | SATELLITE GREY | 1 | 51417476526 | NoS | Shop at ECS Tuning | ||||
| For vehicles with Interior surface Piano Black and Colour Line Satellite Grey and Color Line British Oak and Color Line malt brown and MINI Yours Interior Style Chestnut and MINI Yours Interior Style British Oak and MINI Yours Interior Style Piano Black and Fabric/leatherette in Black Pearl |
S4BDA=Yes S4C3A=No S4F1A=No S4FQA=No S4G5A=Yes S4G6A=Yes S4GVA=Yes KD=Yes |
|||||||||
| 01 | Door trim panel, front left | SHADOW GREY | 1 | 51417476505 | NoS | Shop at ECS Tuning | ||||
| 01 | Door trim panel, front right | SHADOW GREY | 1 | 51417476506 | Shop at ECS Tuning | |||||
| For vehicles with Interior surface Piano Black and Colour Line Satellite Grey and Color Line British Oak and Color Line malt brown and MINI Yours Interior Style Chestnut and MINI Yours Interior Style British Oak and MINI Yours Interior Style Piano Black and Cloth/leather cord |
S4BDA=Yes S4C3A=No S4F1A=No S4FQA=No S4G5A=Yes S4G6A=Yes S4GVA=Yes CX=Yes |
|||||||||
| 01 | Door trim panel, front left | CARBON BLACK | 1 | 51417476509 | Shop at ECS Tuning | |||||
| 01 | Door trim panel, front right | CARBON BLACK | 1 | 51417476510 | Shop at ECS Tuning | |||||
| For vehicles with Interior surface Piano Black and Colour Line Satellite Grey and Color Line British Oak and Color Line malt brown and MINI Yours Interior Style Chestnut and MINI Yours Interior Style British Oak and MINI Yours Interior Style Piano Black and MINI Yours Leather Lounge |
S4BDA=Yes S4C3A=No S4F1A=No S4FQA=No S4G5A=Yes S4G6A=Yes S4GVA=Yes TY=Yes |
|||||||||
| 01 | Door trim panel, front left | CARBON BLACK | 1 | 51417476529 | Shop at ECS Tuning | |||||
| 01 | Door trim panel, front right | CARBON BLACK | 1 | 51417476530 | NoS | Shop at ECS Tuning | ||||
| For vehicles with Interior surface Piano Black and Colour Line Satellite Grey and Color Line British Oak and Color Line malt brown and MINI Yours Interior Style Chestnut and MINI Yours Interior Style British Oak and MINI Yours Interior Style Piano Black and Dinamica/leather |
S4BDA=Yes S4C3A=No S4F1A=No S4FQA=No S4G5A=Yes S4G6A=Yes S4GVA=Yes GS=Yes |
|||||||||
| 01 | Door trim panel, front left | CHILLI RED | 1 | 51417476533 | Shop at ECS Tuning | |||||
| 01 | Door trim panel, front right | CHILLI RED | 1 | 51417476534 | Shop at ECS Tuning | |||||
| For vehicles with Interior surface Piano Black and Colour Line Satellite Grey and Color Line British Oak and Color Line malt brown and MINI Yours Interior Style Chestnut and MINI Yours Interior Style British Oak and MINI Yours Interior Style Piano Black and Leder cross punch or Leather 'Chester' or Leather "Lounge" |
S4BDA=Yes S4C3A=No S4F1A=No S4FQA=No S4G5A=Yes S4G6A=Yes S4GVA=Yes NE=Yes NY=Yes T9=Yes |
|||||||||
| 01 | Door trim panel, front left | CARBON BLACK | 1 | 51417476513 | Shop at ECS Tuning | |||||
| 01 | Door trim panel, front right | CARBON BLACK | 1 | 51417476514 | Shop at ECS Tuning | |||||
| For vehicles with Interior surface Piano Black and Colour Line Satellite Grey and Color Line British Oak and Color Line malt brown and MINI Yours Interior Style Chestnut and MINI Yours Interior Style British Oak and MINI Yours Interior Style Piano Black and FABRIC FIREWORK or FABRIC DOUBLE STRIPE or Imitation leather "Leatherette" |
S4BDA=Yes S4C3A=No S4F1A=No S4FQA=No S4G5A=Yes S4G6A=Yes S4GVA=Yes BG=Yes BZ=Yes K9=Yes |
|||||||||
| 01 | Door trim panel, front left | CARBON BLACK | 1 | 51417476501 | Shop at ECS Tuning | |||||
| 01 | Door trim panel, front right | CARBON BLACK | 1 | 51417476502 | Shop at ECS Tuning | |||||
| 02 | Cover, locking button | 2 | 51417463425 | Shop at ECS Tuning | ||||||
| For vehicles with Hi-Fi System Harman Kardon |
S674A=No |
|||||||||
| 03 | Speaker cover, front left | 1 | 51417441617 | Shop at ECS Tuning | ||||||
| 03 | Speaker cover, front right | 1 | 51417441618 | Shop at ECS Tuning | ||||||
| For vehicles with Chrome Line Interieur and Hi-Fi System Harman Kardon |
S345A=No S674A=Yes |
|||||||||
| 03 | Speaker cover, front left | 1 | 51417404649 | Shop at ECS Tuning | ||||||
| 03 | Speaker cover, front right | 1 | 51417404650 | Shop at ECS Tuning | ||||||
| For vehicles with Chrome Line Interieur and Hi-Fi System Harman Kardon |
S345A=Yes S674A=Yes |
|||||||||
| 03 | Speaker cover, front left | 1 | 51417462135 | Shop at ECS Tuning | ||||||
| 03 | Speaker cover, front right | 1 | 51417462136 | Shop at ECS Tuning | ||||||
| 04 | Clamp | 15 | 51427464307 | Shop at ECS Tuning | ||||||
| For vehicles with MINI Yours Interior Style British Oak and Interior surfaces JCW Piano Black and MINI Yours Interior Style Piano Black |
S4G6A=No S4G9A=No S4GVA=Yes |
|||||||||
| 05 | Trim cover, door, front left | DARK SILVER | 1 | 09/2019 | 51419109699 | Shop at ECS Tuning | ||||
| 05 | Trim cover, door, front right | DARK SILVER | 1 | 09/2019 | 51419109700 | Shop at ECS Tuning | ||||
| For vehicles with Interior surface Piano Black and MINI Yours Interior Style British Oak and Interior surfaces JCW Piano Black and MINI Yours Interior Style Piano Black |
S4BDA=Yes S4G6A=No S4G9A=Yes S4GVA=No |
|||||||||
| 05 | Trim cover, door, front left | PIANO BLACK | 1 | 09/2019 | 51417396713 | Shop at ECS Tuning | ||||
| 05 | Trim cover, door, front right | PIANO BLACK | 1 | 09/2019 | 51417396714 | Shop at ECS Tuning | ||||
| For vehicles with Interior surface Piano Black and MINI Yours Interior Style Chestnut and MINI Yours Interior Style British Oak and MINI Yours interior style gray and MINI Yours Interior Style Piano Black |
S4BDA=No S4G5A=No S4G6A=Yes S4GRA=Yes S4GVA=No |
|||||||||
| 05 | Trim cover, door, front left | BRITISH OAK | 1 | 51417440805 | Shop at ECS Tuning | |||||
| 05 | Trim cover, door, front right | BRITISH OAK | 1 | 51417440806 | NoS | Shop at ECS Tuning | ||||
| 06 | Nut | 6 MM | 11 | 07147141004 | $0.73 | Shop at ECS Tuning | ||||
| 07 | Clamp | 10 | 07147332700 | Shop at ECS Tuning | ||||||
| For vehicles with Light package |
S563A=Yes |
|||||||||
| 08 | LED for interior lamp | HIGH POWER | 1 | 63317941911 | Shop at ECS Tuning | |||||
| 09 | Trim ring, door opener, front left | 1 | 51417390805 | Shop at ECS Tuning | ||||||
| 09 | Trim ring, door opener, front right | 1 | 51417390806 | Shop at ECS Tuning | ||||||
| 10 | Door opener, inner, front right | 1 | 51417360834 | Shop at ECS Tuning | ||||||
| 10 | Door opener, inner, front left | 1 | 51417362993 | Shop at ECS Tuning | ||||||
| 11 | Cover for screw, door opener, front | SCHWARZ | 1 | 51417352949 | Shop at ECS Tuning | |||||
| 11 | Cover, screw, chrome, door opener, front | 1 | 51417359147 | Shop at ECS Tuning | ||||||
| For vehicles with Fold-in outside mirror and Interior/outside mirror with auto dip |
S313A=Yes S430A=Yes |
|||||||||
| 12 | Handle recess driver's side | 1 | 51417411889 | Shop at ECS Tuning | ||||||
| For vehicles with Fold-in outside mirror and Interior/outside mirror with auto dip |
S313A=No S430A=No |
|||||||||
| 12 | Handle recess driver's side | 1 | 51417411888 | Shop at ECS Tuning | ||||||
| 13 | Handle recess passenger's side | 1 | 51417411890 | Shop at ECS Tuning | ||||||
| 14 | Axial securing clip | 5,75MM | 1 | 52207115704 | $0.32 | Shop at ECS Tuning | ||||
| 15 | Fillister head screw | 1 | 61317043728 | $0.38 | Shop at ECS Tuning | |||||
| 16 | Molding cover | 2 | 51417910884 | NoS | Shop at ECS Tuning | |||||
| 17 | Cover plate | SCHWARZ | 1 | 51412457512 | Shop at ECS Tuning | |||||
| For vehicles with automatic trunk lid mechanism |
S316A=Yes |
|||||||||
| 18 | Frame | 1 | 51417411891 | Shop at ECS Tuning | ||||||
| For vehicles with automatic trunk lid mechanism Only fits DTE |
S316A=Yes |
|||||||||
| 19 | Frame | 1 | 51417411892 | Shop at ECS Tuning | ||||||
| 20 | Clamp | 0,8MM | 10 | 51418240509 | $0.74 | Shop at ECS Tuning | ||||
| 21 | Plug-in nut | 4 | 51252753575 | $2.89 | Shop at ECS Tuning | |||||
| 22 | Expanding nut | 2 | 07147265039 | Shop at ECS Tuning | ||||||
| 23 | Fillister head screw | 6 | 07147377159 | Shop at ECS Tuning | ||||||
| 24 | Torx sheet-metal screw | ST4,8X16-R-U1-Z | 2 | 07119907869 | Shop at ECS Tuning | |||||
| 25 | Rotary clip | 2 | 07147216832 | Shop at ECS Tuning | ||||||
| 26 | Stop buffer | 6 | 51437217734 | $2.10 | Shop at ECS Tuning | |||||
| 27 | Gasket | 2 | 51417274654 | Shop at ECS Tuning | ||||||
| 28 | Clip with washer, natur | WEIß | 8 | 51418224768 | $0.69 | Shop at ECS Tuning | ||||
| 29 | Axial securing clip | 2 | 51412756689 | $0.58 | Shop at ECS Tuning | |||||
Notes
- NoS = No Stock (Part centrally not stocked)
