M cover for rocker panel / wheel arch for BMW 6 Series G32 GT LCI 630i (2023)
This M cover for rocker panel / wheel arch technical drawing provides a detailed breakdown of the assembly for the 6 Series G32 GT LCI 630i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2023.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| i | For vehicles with M Aerodynamics package |
S715A=Yes |
||||||||
| 01 | Rocker panel trim, primed, left | -M- LIGHT | 1 | 51778094111 | Shop at ECS Tuning | |||||
| Required for repair | ||||||||||
| -- | Holder, lamp module, left | M | 1 | 63177854483 | Shop at ECS Tuning | |||||
| 01 | Rocker panel trim, primed, right | -M- LIGHT | 1 | 51778094112 | Shop at ECS Tuning | |||||
| Required for repair | ||||||||||
| -- | Holder, lamp module, right | M | 1 | 63177854484 | Shop at ECS Tuning | |||||
| 02 | Air duct, left | -M- | 1 | 51778068577 | Shop at ECS Tuning | |||||
| 02 | Air duct, right | -M- | 1 | 51778068578 | Shop at ECS Tuning | |||||
| 03 | Holder, lamp module, left | M | 1 | 63177854483 | Shop at ECS Tuning | |||||
| 03 | Holder, lamp module, right | M | 1 | 63177854484 | Shop at ECS Tuning | |||||
| 04 | Support strip, rocker panel, left front | 1 | 51177387355 | Shop at ECS Tuning | ||||||
| 04 | Support strip, rocker panel, right front | 1 | 51177387356 | Shop at ECS Tuning | ||||||
| 05 | Support strip, rocker panel, center left | 1 | 51177387357 | Shop at ECS Tuning | ||||||
| 05 | Support strip, rocker panel, center rgt | 1 | 51177387358 | Shop at ECS Tuning | ||||||
| 06 | Mount strip, rocker panel, rear left | 1 | 51177387359 | Shop at ECS Tuning | ||||||
| 06 | Mount strip, rocker panel, rear right | 1 | 51177387360 | Shop at ECS Tuning | ||||||
| 07 | Abrasion protection film for side frame | 2 | 51777385763 | Shop at ECS Tuning | ||||||
| For vehicles with National version japan |
L807A=Yes |
|||||||||
| 08 | Flaired wheel arch, rear left | JAPAN | 1 | 51127423537 | Shop at ECS Tuning | |||||
| 08 | Flaired wheel arch, rear right | JAPAN | 1 | 51127423538 | Shop at ECS Tuning | |||||
| 09 | Abrasion-resistant film | 2 | 51777489805 | Shop at ECS Tuning | ||||||
| 10 | Expanding rivet | 16 | 07147213303 | Shop at ECS Tuning | ||||||
| 11 | Expanding nut | 8X8 MM | 4 | 51127020321 | $0.47 | Shop at ECS Tuning | ||||
| 12 | Hex head screw | 4 | 07147151963 | $0.29 | Shop at ECS Tuning | |||||
| 13 | Clip, grey | 12 | 07147460560 | Shop at ECS Tuning | ||||||
| 14 | C-clip for plastic nut | TS5 | 4 | 07147311312 | Shop at ECS Tuning | |||||
| For vehicles with National version japan |
L807A=Yes |
|||||||||
| 15 | Plastic capnut with washer | D=22MM | 1 | 07147169847 | $0.36 | Shop at ECS Tuning | ||||
| For vehicles with National version japan and National version China |
L807A=Yes L8AAA=Yes |
|||||||||
| 16 | Hexagon screw for plastic | 2 | 07149110670 | $0.71 | Shop at ECS Tuning | |||||
| For vehicles with National version japan and National version China |
L807A=Yes L8AAA=No |
|||||||||
| 16 | Hexagon screw for plastic | 2 | 07149110670 | $0.71 | Shop at ECS Tuning | |||||
| For vehicles with National version japan and National version China |
L807A=No L8AAA=Yes |
|||||||||
| 16 | Hexagon screw for plastic | 2 | 07149110670 | $0.71 | Shop at ECS Tuning | |||||
