Aerokit, trim cover, front for BMW MINI F56 LCI One (2024)
This Aerokit, trim cover, front technical drawing provides a detailed breakdown of the assembly for the MINI F56 LCI One. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2024.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| For vehicles with Park Assistent |
S5DPA=No |
|||||||||
| 01 | Support bumper cover front | JCW | 1 | 51115A3C8A7 | Shop at ECS Tuning | |||||
| For vehicles with Park Assistent |
S5DPA=Yes |
|||||||||
| 01 | Support bumper cover front | JCW PDC | 1 | 51115A3C8A8 | Shop at ECS Tuning | |||||
| 02 | Trim cover, bumper, front left | JCW | 1 | 51115A3C8C5 | Shop at ECS Tuning | |||||
| 02 | Trim cover, bumper, front right | JCW | 1 | 51115A3C8C6 | Shop at ECS Tuning | |||||
| 03 | Bumper trim front bottom left | JCW | 1 | 51115A3C8C7 | Shop at ECS Tuning | |||||
| 03 | Bumper trim front bottom right | JCW | 1 | 51115A3C8C8 | Shop at ECS Tuning | |||||
| 04 | Attachment wheel well left front | JCW | 1 | 51119450607 | Shop at ECS Tuning | |||||
| 04 | Attachment wheel well right front | JCW | 1 | 51119450608 | Shop at ECS Tuning | |||||
| For vehicles with Park Assistent |
S5DPA=Yes |
|||||||||
| 05 | Set of PDC mounts, front | JCW | 1 | 51115A3C8D9 | Shop at ECS Tuning | |||||
| 06 | Front left air duct cover | JCW | 1 | 51119450635 | Shop at ECS Tuning | |||||
| 06 | Front right air duct cover | JCW | 1 | 51119450636 | Shop at ECS Tuning | |||||
| 07 | Cover, air duct, brake left | JCW | 1 | 51119450631 | Shop at ECS Tuning | |||||
| 07 | Cover, air duct, brake right | JCW | 1 | 51119450632 | Shop at ECS Tuning | |||||
| For vehicles with National version japan and Control of number-plate attachment |
L807A=Yes S992A=Yes |
|||||||||
| 08 | License-plate carrier front | JCW US/ JAP | 1 | 51749853980 | Shop at ECS Tuning | |||||
| For vehicles with National version japan and National version China and Control of number-plate attachment |
L807A=No L8AAA=No S992A=No |
|||||||||
| 08 | License-plate carrier front | JCW ECE | 1 | 51749853982 | Shop at ECS Tuning | |||||
| 09 | Countersunk screw | M6X20-PCU2-10.9 | 4 | 07119908698 | Shop at ECS Tuning | |||||
| 10 | Fillister head screw | 4 | 07147197262 | Shop at ECS Tuning | ||||||
| 11 | C-clip for plastic nut | TS5 | 4 | 07147311312 | Shop at ECS Tuning | |||||
| 12 | Blind rivet | 8 | 07147191115 | $0.26 | Shop at ECS Tuning | |||||
