Trim cover, rear for BMW MINI F55 LCI One (2024)
This Trim cover, rear technical drawing provides a detailed breakdown of the assembly for the MINI F55 LCI One. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2024.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| i | For vehicles with JCW Aerodynamics kit |
S3A1A=No |
||||||||
| 01 | Bumper trim panel, rear, top | 1 | 51125A3CAC2 | Shop at ECS Tuning | ||||||
| only in conjunction with | ||||||||||
| -- | Kit add-ons rear bumper | VALUE PARTS | 1 | 51125B39770 | Shop at ECS Tuning | |||||
| For vehicles with Park Distance Control (PDC), rear and Park Assistent |
S507A=Yes S5DPA=Yes |
|||||||||
| 01 | Bumper trim panel, rear, top | PDC | 1 | 51125A3CAC1 | Shop at ECS Tuning | |||||
| only in conjunction with | ||||||||||
| -- | Kit add-ons rear bumper | VALUE PARTS | 1 | 51125B39770 | Shop at ECS Tuning | |||||
| For vehicles with Park Distance Control (PDC), rear and Park Assistent |
S507A=Yes S5DPA=No |
|||||||||
| 01 | Bumper trim panel, rear, top | PDC | 1 | 51125A3CAC1 | Shop at ECS Tuning | |||||
| only in conjunction with | ||||||||||
| -- | Kit add-ons rear bumper | VALUE PARTS | 1 | 51125B39770 | Shop at ECS Tuning | |||||
| For vehicles with Park Distance Control (PDC), rear and Park Assistent |
S507A=No S5DPA=Yes |
|||||||||
| 01 | Bumper trim panel, rear, top | PDC | 1 | 51125A3CAC1 | Shop at ECS Tuning | |||||
| only in conjunction with | ||||||||||
| -- | Kit add-ons rear bumper | VALUE PARTS | 1 | 51125B39770 | Shop at ECS Tuning | |||||
| For vehicles with Park Distance Control (PDC), rear and Park Assistent |
S507A=Yes S5DPA=Yes |
|||||||||
| 02 | Trim panel, bumper, rear, bottom | ECE PDC | 1 | 51125A3CAC5 | Shop at ECS Tuning | |||||
| only in conjunction with | ||||||||||
| -- | Expanding rivet | D = 6MM | 2 | 51111908077 | $0.30 | Shop at ECS Tuning | ||||
| For vehicles with Park Distance Control (PDC), rear and Park Assistent |
S507A=Yes S5DPA=No |
|||||||||
| 02 | Trim panel, bumper, rear, bottom | ECE PDC | 1 | 51125A3CAC5 | Shop at ECS Tuning | |||||
| only in conjunction with | ||||||||||
| -- | Expanding rivet | D = 6MM | 2 | 51111908077 | $0.30 | Shop at ECS Tuning | ||||
| For vehicles with Park Distance Control (PDC), rear and Park Assistent |
S507A=No S5DPA=Yes |
|||||||||
| 02 | Trim panel, bumper, rear, bottom | ECE PDC | 1 | 51125A3CAC5 | Shop at ECS Tuning | |||||
| only in conjunction with | ||||||||||
| -- | Expanding rivet | D = 6MM | 2 | 51111908077 | $0.30 | Shop at ECS Tuning | ||||
| For vehicles with Park Distance Control (PDC), rear and Park Assistent |
S507A=No S5DPA=No |
|||||||||
| 02 | Trim panel, bumper, rear, bottom | ECE | 1 | 51125A3CAC3 | Shop at ECS Tuning | |||||
| only in conjunction with | ||||||||||
| -- | Expanding rivet | D = 6MM | 2 | 51111908077 | $0.30 | Shop at ECS Tuning | ||||
| 03 | Trim cover, tow fitting, rear | 1 | 51119450684 | Shop at ECS Tuning | ||||||
| 04 | Cover, bumper, rear primed | 1 | 51115A40E35 | Shop at ECS Tuning | ||||||
| For vehicles with Park Distance Control (PDC), rear and Park Assistent |
S507A=Yes S5DPA=Yes |
|||||||||
| 05 | Rear PDC holder set | ONE | 1 | 51125A3CAC7 | Shop at ECS Tuning | |||||
| For vehicles with Park Distance Control (PDC), rear and Park Assistent |
S507A=Yes S5DPA=No |
|||||||||
| 05 | Rear PDC holder set | ONE | 1 | 51125A3CAC7 | Shop at ECS Tuning | |||||
| For vehicles with Park Distance Control (PDC), rear and Park Assistent |
S507A=No S5DPA=Yes |
|||||||||
| 05 | Rear PDC holder set | ONE | 1 | 51125A3CAC7 | Shop at ECS Tuning | |||||
| 06 | Guide for bumper, side, left | 1 | 51119450585 | Shop at ECS Tuning | ||||||
| 06 | Guide for bumper, side, right | 1 | 51119450586 | Shop at ECS Tuning | ||||||
| 07 | Breather covering rear | 1 | 51127302547 | Shop at ECS Tuning | ||||||
| 07 | Breather covering rear | 1 | 51125A2FB49 | Shop at ECS Tuning | ||||||
| 08 | Torx screw | 4 | 07149194838 | $0.38 | Shop at ECS Tuning | |||||
| 09 | Blind rivet nut, flat headed | M5 | 4 | 07147411141 | Shop at ECS Tuning | |||||
| 10 | Hex bolt | TS5X20 SW8 D=22 | 8 | 07149213164 | $0.38 | Shop at ECS Tuning | ||||
| 11 | Combination nut | 14 | 07147305178 | Shop at ECS Tuning | ||||||
