Door trim panel, front for BMW 2 Series U06 Active Tourer 218d (2025)
This Door trim panel, front technical drawing provides a detailed breakdown of the assembly for the 2 Series U06 Active Tourer 218d. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2025.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| For vehicles with Cloth Arcturus/anthracite |
BLAT=Yes |
|||||||||
| 01 | Front door trim panel left | ANTHRAZIT | 1 | 51415A53311 | NoS | Shop at ECS Tuning | ||||
| 01 | Door trim panel, front right | ANTHRAZIT | 1 | 51415A53312 | NoS | Shop at ECS Tuning | ||||
| For vehicles with Alcan./Veganza-comb.Blk./Contr.st.Blue |
KTNL=Yes |
|||||||||
| 01 | Left front door trim panel | SCHWARZ | 1 | 07/2023 | 51415A5F931 | NoS | Shop at ECS Tuning | |||
| 01 | Right front door trim panel | SCHWARZ | 1 | 07/2023 | 51415A5F932 | NoS | Shop at ECS Tuning | |||
| For vehicles with VEGANZA PERFORATED MOCHA or Leather Vernasca/mocca |
KUMY=Yes MAMY=Yes |
|||||||||
| 01 | Left front door trim panel | MOKKA | 1 | 07/2023 | 51415A5F923 | NoS | Shop at ECS Tuning | |||
| 01 | Right front door trim panel | MOKKA | 1 | 07/2023 | 51415A5F924 | NoS | Shop at ECS Tuning | |||
| For vehicles with VEGANZA PERFORATED OYSTER or Leather Vernasca/oyster |
KUCX=Yes MACX=Yes |
|||||||||
| 01 | Left front door trim panel | OYSTER | 1 | 07/2023 | 51415A5F927 | NoS | Shop at ECS Tuning | |||
| 01 | Right front door trim panel | OYSTER | 1 | 07/2023 | 51415A5F928 | NoS | Shop at ECS Tuning | |||
| For vehicles with VEGANZA PERFORATED BLACK or Leather Vernasca black |
KUSW=Yes MASW=Yes |
|||||||||
| 01 | Left front door trim panel | SCHWARZ | 1 | 07/2023 | 51415A5F921 | NoS | Shop at ECS Tuning | |||
| 01 | Right front door trim panel | SCHWARZ | 1 | 07/2023 | 51415A5F922 | NoS | Shop at ECS Tuning | |||
| 02 | Clip | 16 | 07145A444B5 | Shop at ECS Tuning | ||||||
| 03 | Plug-in nut | 4 | 51252753575 | $2.89 | Shop at ECS Tuning | |||||
| 04 | Screw | 5X20 | 8 | 07129909320 | Shop at ECS Tuning | |||||
| 05 | Torx-bolt for plastic material | ISA L=22MM | 4 | 84137007031 | $0.62 | Shop at ECS Tuning | ||||
| 06 | Stop buffer | 6 | 51437217734 | $2.10 | Shop at ECS Tuning | |||||
Notes
- NoS = No Stock (Part centrally not stocked)
