Rear cover for BMW 3 Series E30 320i (1990)
This Rear cover technical drawing provides a detailed breakdown of the assembly for the 3 Series E30 320i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1990.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| i | Version 310 | |||||||||
| 02 | Cover backrest cloth | 0211 ANTHRAZIT | 1 | 09/1985 | 52201943548 | ENDED | Shop at ECS Tuning | |||
| 02 | Cover backrest cloth | 0212 PACIFIC | 1 | 09/1985 | 52201943549 | $158.47 | ENDED | Shop at ECS Tuning | ||
| 02 | Cover backrest cloth | 0213 NUTRIA | 1 | 09/1985 | 52201943550 | $158.47 | ENDED | Shop at ECS Tuning | ||
| 02 | Cover backrest cloth | 0214 PERLBEIGE | 1 | 09/1985 | 52201943551 | $158.47 | ENDED | Shop at ECS Tuning | ||
| 02 | Cover backrest cloth | 0215 PINIENGR. | 1 | 09/1985 | 52201943552 | $158.47 | ENDED | Shop at ECS Tuning | ||
| 02 | Cover backrest, imitation leather | 0166 SCHWARZ | 1 | 09/1985 | 52201943562 | ENDED | Shop at ECS Tuning | |||
| 02 | Cover backrest, imitation leather | 0167 PACIFIC | 1 | 09/1985 | 52201943563 | $126.11 | ENDED | Shop at ECS Tuning | ||
| 02 | Cover backrest, imitation leather | 0156 PERLBEIGE | 1 | 09/1985 | 52201943564 | ENDED | Shop at ECS Tuning | |||
| 02 | Cover backrest, leather | 0203 SCHWARZ | 1 | 09/1985 | 52201943576 | $635.09 | ENDED | Shop at ECS Tuning | ||
| 02 | Cover backrest, leather | 0204 PACIFIC | 1 | 09/1985 | 52201943577 | $599.85 | ENDED | Shop at ECS Tuning | ||
| 02 | Cover backrest, leather | 0205 NUTRIA | 1 | 09/1985 | 52201943578 | $630.54 | ENDED | Shop at ECS Tuning | ||
| 02 | Cover backrest, leather | 0206 PERLBEIGE | 1 | 09/1985 | 52201943579 | $599.85 | ENDED | Shop at ECS Tuning | ||
| 02 | Cover backrest, leather | 0208 TAURUSROT | 1 | 09/1985 | 52201943580 | $599.85 | ENDED | Shop at ECS Tuning | ||
| 02 | Cover backrest, leather | 0256 CARDIN.ROT | 1 | 09/1985 | 52201966729 | $599.85 | ENDED | Shop at ECS Tuning | ||
| 02 | Cover backrest cloth | 0269 ANTHRAZIT | 1 | 09/1985 | 52208103895 | $214.27 | ENDED | Shop at ECS Tuning | ||
| 02 | Cover backrest cloth | 0270 SILBER | 1 | 09/1985 | 52208103896 | $271.01 | ENDED | Shop at ECS Tuning | ||
| 02 | Cover backrest cloth | 0271 INDIGO | 1 | 09/1985 | 52208103897 | $214.27 | ENDED | Shop at ECS Tuning | ||
| 02 | Cover backrest cloth | 0272 HAVANNA | 1 | 09/1985 | 52208103898 | $214.27 | ENDED | Shop at ECS Tuning | ||
| 02 | Cover backrest cloth | 0273 NATUR | 1 | 09/1985 | 52208103899 | $271.01 | ENDED | Shop at ECS Tuning | ||
| 02 | Cover backrest, imitation leather | 0192 NATUR | 1 | 09/1985 | 52208103902 | $271.01 | ENDED | Shop at ECS Tuning | ||
| 02 | Cover backrest, leather | 0292 SILBER | 1 | 09/1985 | 52208103904 | $599.85 | ENDED | Shop at ECS Tuning | ||
| 02 | Cover backrest, leather | 0293 INDIGO | 1 | 09/1985 | 52208103905 | $599.85 | ENDED | Shop at ECS Tuning | ||
| 02 | Cover backrest, leather | 0295 NATUR | 1 | 09/1985 | 52208103906 | $599.85 | ENDED | Shop at ECS Tuning | ||
| 02 | Cover backrest, leather | 0296 CARDIN.ROT | 1 | 09/1985 | 52208103907 | ENDED | Shop at ECS Tuning | |||
| 02 | Cover backrest, leather | 0324 KARMES.ROT | 1 | 09/1985 | 52208112385 | $599.85 | ENDED | Shop at ECS Tuning | ||
| ONLY APPLIES TO EDITION | ||||||||||
| 02 | Cover backrest cloth | 0376 ANTHRAZIT | 1 | 12/1989 | 52208129642 | ENDED | Shop at ECS Tuning | |||
| 02 | Cover backrest cloth | 0377 SILBER | 1 | 12/1989 | 52208129643 | ENDED | Shop at ECS Tuning | |||
| 02 | Cover backrest cloth | 0378 INDIGO | 1 | 12/1989 | 52208129644 | ENDED | Shop at ECS Tuning | |||
| ONLY APPLIES TO EDITION | ||||||||||
| 02 | Cover backrest cloth | 0376 ANTHRAZIT | 1 | 12/1989 | 52208129869 | ENDED | Shop at ECS Tuning | |||
| 02 | Cover backrest cloth | 0377 SILBER | 1 | 12/1989 | 52208129870 | ENDED | Shop at ECS Tuning | |||
| 02 | Cover backrest cloth | 0378 INDIGO | 1 | 12/1989 | 52208129871 | ENDED | Shop at ECS Tuning | |||
Notes
- ENDED = the part has been discontinued (no longer available).
