BMW sportseat el.adjustable headrest for BMW 5 Series E28 535i (1987)
This BMW sportseat el.adjustable headrest technical drawing provides a detailed breakdown of the assembly for the 5 Series E28 535i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1987.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| i | Ausführung 546 | |||||||||
| 05 | Slider | LAMA | 4 | 01/1986 | 52101919787 | ENDED | Shop at ECS Tuning | |||
| 05 | Slider | ANTHRAZIT | 4 | 01/1986 | 52101934694 | $17.12 | ENDED | Shop at ECS Tuning | ||
| 05 | Slider | PACIFIC | 4 | 01/1986 | 52101934695 | $5.91 | ENDED | Shop at ECS Tuning | ||
| 05 | Slider | NUTRIA | 4 | 01/1986 | 52101934696 | $5.91 | ENDED | Shop at ECS Tuning | ||
| 05 | Slider | PERLBEIGE | 4 | 01/1986 | 52101934697 | $0.90 | ENDED | Shop at ECS Tuning | ||
| 05 | Slider | PINIENGRUEN | 4 | 01/1986 | 52101934698 | $1.14 | ENDED | Shop at ECS Tuning | ||
Notes
- ENDED = the part has been discontinued (no longer available).
