Pucci individual fabric meterware for BMW 7 Series E38 750iL (1998)
This Pucci individual fabric meterware technical drawing provides a detailed breakdown of the assembly for the 7 Series E38 750iL. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1998.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| i | Pucci, patterned, beige 03-80 Pucci patterned, maulbeere 03-40 Pucci patterned, petrol 03-60 Pucci patterned, silk 03-10 Pucci patterned, velvetblue 03-50 Pucci, unicolor, beige 04-80 Pucci, unicolor, maulbeere 04-40 Pucci, unicolor, petrol 04-60 Pucci, unicolor, silk 04-10 Pucci, unicolor, velvet blue 04-50 |
|||||||||
| Material by the meter for: Main seat parts (center) Width = 1500mm |
||||||||||
| 01 | upholstery cloth Pucci, patterned | BEIGE | X | 51922493769 | $163.65 | ENDED, NoS | Shop at ECS Tuning | |||
| 01 | upholstery cloth Pucci, patterned | MAULBEERE | X | 51922493770 | $135.04 | ENDED, NoS | Shop at ECS Tuning | |||
| 01 | upholstery cloth Pucci, patterned | PETROL | X | 51922493771 | $135.04 | ENDED, NoS | Shop at ECS Tuning | |||
| 01 | upholstery cloth Pucci, patterned | SILK | X | 51922493772 | $135.04 | ENDED, NoS | Shop at ECS Tuning | |||
| 01 | upholstery cloth Pucci, patterned | VELVETBLUE | X | 51922493773 | $135.04 | ENDED, NoS | Shop at ECS Tuning | |||
| Material by the meter for: Door insert (door mirror) fits only E38 |
||||||||||
| 04 | upholstery cloth Pucci, patterned | BEIGE | X | 51922493775 | $73.94 | ENDED, NoS | Shop at ECS Tuning | |||
| 04 | upholstery cloth Pucci, patterned | MAULBEERE | X | 51922493776 | ENDED, NoS | Shop at ECS Tuning | ||||
| 04 | upholstery cloth Pucci, patterned | PETROL | X | 51922493777 | ENDED, NoS | Shop at ECS Tuning | ||||
| 04 | upholstery cloth Pucci, patterned | SILK | X | 51922493778 | ENDED, NoS | Shop at ECS Tuning | ||||
| 04 | upholstery cloth Pucci, patterned | VALVETBLUE | X | 51922493779 | ENDED, NoS | Shop at ECS Tuning | ||||
Notes
- ENDED = the part has been discontinued (no longer available).
- NoS = No Stock (Part centrally not stocked)
