Headrest front for BMW 2500-3.3Li 2800 (1971)
This Headrest front technical drawing provides a detailed breakdown of the assembly for the 2500-3.3Li 2800. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1971.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Sleeve | 10 MM | 4 | 08/1968 | 02/1977 | 52101806881 | $17.63 | ENDED | Shop at ECS Tuning | |
| 01 | Sleeve | 12 MM | 4 | 08/1968 | 02/1977 | 52101824567 | ENDED | Shop at ECS Tuning | ||
| 02 | Spring | 4 | 08/1968 | 02/1977 | 52101805618 | $11.94 | ENDED | Shop at ECS Tuning | ||
| 02 | Spring | 4 | 08/1968 | 02/1977 | 52101823938 | ENDED | Shop at ECS Tuning | |||
| 03 | Cover | 4 | 08/1968 | 02/1977 | 52101805732 | ENDED | Shop at ECS Tuning | |||
| 03 | Covering piece chromed | 4 | 08/1968 | 02/1977 | 52101819850 | $19.96 | Shop at ECS Tuning | |||
| 03 | Covering piece | SCHWARZ | 4 | 08/1968 | 02/1977 | 52101828905 | $13.32 | Shop at ECS Tuning | ||
| 04 | Cover | 4 | 08/1968 | 02/1977 | 52101804556 | $4.02 | ENDED | Shop at ECS Tuning | ||
| 04 | Covering piece chromed | 4 | 08/1968 | 02/1977 | 52101820742 | ENDED | Shop at ECS Tuning | |||
| 04 | Covering piece Black | 4 | 08/1968 | 02/1977 | 52101828907 | ENDED | Shop at ECS Tuning | |||
| 05 | Clamp | 18 | 52117002556 | ENDED | Shop at ECS Tuning | |||||
| 06 | Sleeve | 2 | 08/1968 | 02/1977 | 52101830644 | ENDED | Shop at ECS Tuning |
Notes
- ENDED = the part has been discontinued (no longer available).
