Headrest front,adjustable for BMW 2500-3.3Li 3.0Si (1975)
This Headrest front,adjustable technical drawing provides a detailed breakdown of the assembly for the 2500-3.3Li 3.0Si. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1975.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Sleeve | 8 | 52101838965 | $0.61 | Shop at ECS Tuning | |||||
| 02 | Spring | 2 | 52101838966 | $0.44 | ENDED | Shop at ECS Tuning | ||||
| 03 | Lock lever | 2 | 52101838094 | ENDED | Shop at ECS Tuning | |||||
| 04 | Covering Lower | 4 | 52101838969 | $0.43 | Shop at ECS Tuning | |||||
| 05 | Cover | SCHWARZ | 4 | 52108191245 | $1.66 | Shop at ECS Tuning | ||||
| 06 | Clamp | 2 | 51411870718 | $0.24 | Shop at ECS Tuning | |||||
| 07 | Button | 2 | 52101838967 | $0.50 | Shop at ECS Tuning |
Notes
- ENDED = the part has been discontinued (no longer available).
