Seat, front, comfort functions for BMW XM G09 XM (2025)
This Seat, front, comfort functions technical drawing provides a detailed breakdown of the assembly for the XM G09 XM. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2025.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| For vehicles with Massage function, driver / fr. passenger |
S4T7A=No |
|||||||||
| 02 | Lumbar support pad with pump | 2 | 52107473983 | NoS | Shop at ECS Tuning | |||||
| For vehicles with Massage function, driver / fr. passenger |
S4T7A=Yes |
|||||||||
| 04 | Pneumatic seat mat, front left | 1 | 08/2021 | 52105A1A503 | NoS | Shop at ECS Tuning | ||||
| 04 | Pneumatic seat mat | CAN-MODUL | 1 | 08/2021 | 52105A1A506 | NoS | Shop at ECS Tuning | |||
| 05 | Massage pump | 2 | 52107357427 | Shop at ECS Tuning | ||||||
| 06 | Active seat upholstery, seat cushion | 2 | 52107368557 | Shop at ECS Tuning | ||||||
Notes
- NoS = No Stock (Part centrally not stocked)
See Also
Frequently Asked Questions
- What assembly is shown in the BMW XM G09 XM Seat, front, comfort functions?
- This technical diagram illustrates the Seat, front, comfort functions within the Seats group for the XM G09 XM produced during 2025. It provides a detailed exploded view of the components, identifying key parts such as the Lumbar support pad with pump (Part #52107473983).
- Which models use the hardware listed in this Seat, front, comfort functions?
- The hardware and components featured in the Seat, front, comfort functions are specific to the XM G09 XM produced during 2025. These technical specifications ensure that parts like the Lumbar support pad with pump (52107473983) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Seat, front, comfort functions assembly?
- Each item in the Seat, front, comfort functions corresponds to the numbered list below the illustration. For the XM G09 XM, you can identify the Lumbar support pad with pump by locating its position on the schematic, which then links to the official BMW part number 52107473983 for the Seats section.
