Seat front seat coverings for BMW 5 Series G99 M5 Touring M5 (2025)
This Seat front seat coverings technical drawing provides a detailed breakdown of the assembly for the 5 Series G99 M5 Touring M5. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2025.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| For vehicles with Leather Merino/Silverstone/black or Leather 'Merino' red/black or Leather Merino/Kyalami orange/black or Leather "Merino"/schwarz |
LKIA=Yes LKKG=Yes LKKX=Yes LKSW=Yes |
|||||||||
| 01 | Blende Sitz außen links | SCHWARZ | 1 | 52105A5C167 | NoS | Shop at ECS Tuning | ||||
| 01 | Blende Sitz außen rechts | SCHWARZ | 1 | 52105A5C168 | NoS | Shop at ECS Tuning | ||||
| 02 | Seat trim inner left | SCHWARZ | 1 | 52105A53547 | NoS | Shop at ECS Tuning | ||||
| 02 | Seat trim inner right | SCHWARZ | 1 | 52105A53548 | NoS | Shop at ECS Tuning | ||||
| 03 | Support, trim, seat, left | SCHWARZ | 1 | 52105A5C153 | NoS | Shop at ECS Tuning | ||||
| 03 | Support, trim, seat, right | SCHWARZ | 1 | 52105A5C154 | NoS | Shop at ECS Tuning | ||||
| 04 | Trim, front seat | 2 | 52105A178F8 | NoS | Shop at ECS Tuning | |||||
| For vehicles with Leather Merino/Silverstone/black or Leather 'Merino' red/black or Leather Merino/Kyalami orange/black or Leather "Merino"/schwarz |
LKIA=Yes LKKG=Yes LKKX=Yes LKSW=Yes |
|||||||||
| 05 | Cover cap, seat rail front left | SCHWARZ | 2 | 52105A41FE3 | NoS | Shop at ECS Tuning | ||||
| 05 | Cover cap, seat rail front right | SCHWARZ | 2 | 52105A41FE4 | NoS | Shop at ECS Tuning | ||||
| 06 | Protective cap, seat rail, rear left | SCHWARZ | 2 | 52105A41FF3 | NoS | Shop at ECS Tuning | ||||
| 06 | Protective cap, seat rail, right rear | SCHWARZ | 2 | 52105A41FF4 | NoS | Shop at ECS Tuning | ||||
| 07 | Main small parts kit | 1 | 52108087849 | Shop at ECS Tuning | ||||||
| 08 | Clamp | 4 | 52107068032 | $0.71 | Shop at ECS Tuning | |||||
Notes
- NoS = No Stock (Part centrally not stocked)
