Rollover protection system for BMW 3 Series E36 M3 (1995)
This Rollover protection system technical drawing provides a detailed breakdown of the assembly for the 3 Series E36 M3. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1995.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| i | Cannot be retrofitted | |||||||||
| 01 | Rollover bar | 2 | 54628173727 | $1180.44 | +core | Shop at ECS Tuning | ||||
| 02 | Torx-bolt with washer | ISA M8X18 | X | 07142756941 | $1.16 | Shop at ECS Tuning | ||||
| FOR VEHICLES WITH AND WITHOUT HARDTOP MODEL SOFT |
||||||||||
| 03 | Covering cap | SCHWARZ | 2 | 54628174181 | $70.52 | +core | Shop at ECS Tuning | |||
| 04 | Emergency mechanism | 1 | 54628165663 | $44.62 | +core | Shop at ECS Tuning | ||||
Notes
- +core = plus core charge (possibility of a return of the old part)
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 3 Series E36 M3 Rollover protection system?
- This technical diagram illustrates the Rollover protection system within the Sliding Roof / Folding Top group for the 3 Series E36 M3 produced during 1995. It provides a detailed exploded view of the components, identifying key parts such as the Rollover bar (Part #54628173727).
- Which models use the hardware listed in this Rollover protection system?
- The hardware and components featured in the Rollover protection system are specific to the 3 Series E36 M3 produced during 1995. These technical specifications ensure that parts like the Rollover bar (54628173727) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Rollover protection system assembly?
- Each item in the Rollover protection system corresponds to the numbered list below the illustration. For the 3 Series E36 M3, you can identify the Rollover bar by locating its position on the schematic, which then links to the official BMW part number 54628173727 for the Sliding Roof / Folding Top section.
