Convertible top compartment for BMW 2 Series F23 LCI 218i (2021)
This Convertible top compartment technical drawing provides a detailed breakdown of the assembly for the 2 Series F23 LCI 218i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2021.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Folding top compartment | 1 | 51177300968 | Shop at ECS Tuning | ||||||
| 02 | Bracket micro switch | 1 | 54347186769 | $15.31 | Shop at ECS Tuning | |||||
| 03 | Pin | 2 | 54347186794 | $1.72 | Shop at ECS Tuning | |||||
| 04 | ISA screw | M6X14 | 1 | 07129903027 | $1.20 | Shop at ECS Tuning | ||||
| 05 | Clip | 6 | 54347203393 | Shop at ECS Tuning | ||||||
| 07 | Expanding rivet | 8 | 07147346587 | Shop at ECS Tuning |
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 2 Series F23 LCI 218i Convertible top compartment?
- This technical diagram illustrates the Convertible top compartment within the Sliding Roof / Folding Top group for the 2 Series F23 LCI 218i produced during 2021. It provides a detailed exploded view of the components, identifying key parts such as the Folding top compartment (Part #51177300968).
- Which models use the hardware listed in this Convertible top compartment?
- The hardware and components featured in the Convertible top compartment are specific to the 2 Series F23 LCI 218i produced during 2021. These technical specifications ensure that parts like the Folding top compartment (51177300968) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Convertible top compartment assembly?
- Each item in the Convertible top compartment corresponds to the numbered list below the illustration. For the 2 Series F23 LCI 218i, you can identify the Folding top compartment by locating its position on the schematic, which then links to the official BMW part number 51177300968 for the Sliding Roof / Folding Top section.
