SHD - sliding headliner for BMW 5 Series G30 520d (2019)
This SHD - sliding headliner technical drawing provides a detailed breakdown of the assembly for the 5 Series G30 520d. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2019.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| i | For vehicles with Glass roof, electrical |
S403A=Yes |
||||||||
| For vehicles with Headlining anthracite |
S775A=Yes |
|||||||||
| 01 | Sliding headliner | ANTHRAZIT | 1 | 07/2020 | 54108049081 | Shop at ECS Tuning | ||||
| For vehicles with Headliner in Alcantara anthracite |
S776A=Yes |
|||||||||
| 01 | Sliding headliner Alcantara | SCHWARZ | 1 | 54108073718 | NoS | Shop at ECS Tuning | ||||
| For vehicles with Headlining anthracite and Headlining anthracite and Headliner in Alcantara anthracite and Sensatec perforated/Canberra beige or Sensatec perforated/Canberra beige or Leather Dakota/canberra-beige or Leather Dakota/Canberra beige/excl.seam or Leather Dakota/canberra-beige or Leather Dakota Canberra beige or Leather 'Dakota' canberrabeige / black or Leather 'Nappa' extended/canberra-beige or Leather 'Nappa' extended/canberra-beige or Leather 'Nappa' extended/zagora-beige |
S4AAA=No S775A=No S776A=No KHCY=Yes KHFY=Yes LCCY=Yes LCDO=Yes LCDQ=Yes LCEA=Yes LCFY=Yes NACY=Yes NADQ=Yes NAFZ=Yes |
|||||||||
| 01 | Sliding headliner | CANBERRABEIGE | 1 | 54107214896 | Shop at ECS Tuning | |||||
| For vehicles with Headlining anthracite and Headlining anthracite and Headliner in Alcantara anthracite and Cloth junction / anthracite or Cloth/leather plectoid / anthracite or Imitation leather "Leatherette/black" or Cloth/Sensatec/anthracite or Sensatec perforated/cognac or Sensatec perforated/black or Leather "Dakota/elfenbein-weiss" or Leather Dakota/elfenbein-weiss/Excl.seam or Leather Dakota/elfenbein-weiss/Excl.seam or Leather Dakota/black/excl. seam or Leather Dakota/tacora red or Leather, Dakota/cognac or Leather Dakota/Cognac/exclusive seam or Leather "Dakota"/schwarz or Leather Dakota/night blue/exclusive seam or Exclusive leather Nappa/ivory white or Exclusive leather Nappa/ivory white or Excl.leather Nappa/black/exclusive seam or Excl. leather Nappa/mocca/exclusive seam |
S4AAA=No S775A=No S776A=No BYAT=Yes CNAT=Yes K8SW=Yes KFAT=Yes KHRI=Yes KHSW=Yes LCEW=Yes LCFF=Yes LCFI=Yes LCFK=Yes LCG7=Yes LCRI=Yes LCRO=Yes LCSW=Yes LCTJ=Yes LZFF=Yes LZFI=Yes LZFK=Yes LZNI=Yes |
|||||||||
| 01 | Sliding headliner | ELFENBEINWEISS | 1 | 54107214895 | Shop at ECS Tuning | |||||
| 02 | Slider f sliding headliner | 1 | 54107209209 | $18.57 | Shop at ECS Tuning | |||||
Notes
- NoS = No Stock (Part centrally not stocked)
