Cab for BMW 5 Series E34 525tds (1995)
This Cab technical drawing provides a detailed breakdown of the assembly for the 5 Series E34 525tds. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1995.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Taxi plate control light | 1 | 65721391288 | ENDED | Shop at ECS Tuning | |||||
| 02 | Switch taxi-lamp | 1 | 61311376753 | ENDED | Shop at ECS Tuning | |||||
| 03 | Plug-in socket f taxi plate | 1 | 61131382980 | ENDED | Shop at ECS Tuning | |||||
| 04 | Taxi plate line | 1 | 61121391359 | ENDED | Shop at ECS Tuning | |||||
| 05 | Loudspeaker | 1 | 65131388285 | ENDED | Shop at ECS Tuning | |||||
| 06 | Cover Loudspeaker | SCHWARZ | 1 | 65131390376 | ENDED | Shop at ECS Tuning | ||||
| 07 | Clamp f taxi plate light cable | 1 | 61131391420 | ENDED | Shop at ECS Tuning | |||||
| 08 | Pulse adapter | INTERNE NUMMER | 1 | 61311376455 | ENDED | Shop at ECS Tuning | ||||
| 09 | Alarm switch | 1 | 61311376401 | ENDED | Shop at ECS Tuning | |||||
| 10 | Microswitch | 1 | 61311375880 | ENDED | Shop at ECS Tuning |
Notes
- ENDED = the part has been discontinued (no longer available).
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 5 Series E34 525tds Cab?
- This technical diagram illustrates the Cab within the Vehicle electrical system group for the 5 Series E34 525tds produced during 1995. It provides a detailed exploded view of the components, identifying key parts such as the Taxi plate control light (Part #65721391288).
- Which models use the hardware listed in this Cab?
- The hardware and components featured in the Cab are specific to the 5 Series E34 525tds produced during 1995. These technical specifications ensure that parts like the Taxi plate control light (65721391288) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Cab assembly?
- Each item in the Cab corresponds to the numbered list below the illustration. For the 5 Series E34 525tds, you can identify the Taxi plate control light by locating its position on the schematic, which then links to the official BMW part number 65721391288 for the Vehicle electrical system section.
