Battery cable for BMW 6 Series E24 635CSi (1989)
This Battery cable technical drawing provides a detailed breakdown of the assembly for the 6 Series E24 635CSi. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1989.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Battery cable (plus pole) | L=760MM | 1 | 08/1978 | 12421277516 | $26.61 | ENDED | Shop at ECS Tuning | ||
| 03 | Battery cable negative | L=790MM | 1 | 12421286746 | $19.48 | Shop at ECS Tuning |
Notes
- ENDED = the part has been discontinued (no longer available).
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 6 Series E24 635CSi Battery cable?
- This technical diagram illustrates the Battery cable within the Vehicle electrical system group for the 6 Series E24 635CSi produced during 1989. It provides a detailed exploded view of the components, identifying key parts such as the Battery cable (plus pole) (Part #12421277516).
- Which models use the hardware listed in this Battery cable?
- The hardware and components featured in the Battery cable are specific to the 6 Series E24 635CSi produced during 1989. These technical specifications ensure that parts like the Battery cable (plus pole) (12421277516) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Battery cable assembly?
- Each item in the Battery cable corresponds to the numbered list below the illustration. For the 6 Series E24 635CSi, you can identify the Battery cable (plus pole) by locating its position on the schematic, which then links to the official BMW part number 12421277516 for the Vehicle electrical system section.
