Cable covering for BMW 5 Series E34 530i (1996)
This Cable covering technical drawing provides a detailed breakdown of the assembly for the 5 Series E34 530i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1996.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Front left cable covering | 1 | 61131384029 | $6.14 | Shop at ECS Tuning | |||||
| 01 | Front right cable covering | 1 | 61131384030 | $9.60 | Shop at ECS Tuning | |||||
| 02 | Rear left cable covering | 1 | 61131384017 | $5.03 | Shop at ECS Tuning | |||||
| 02 | Rear right cable covering | 1 | 61131384018 | $8.04 | ENDED | Shop at ECS Tuning | ||||
| 03 | Cable covering f seat carrier | 2 | 61131382380 | $6.47 | ENDED | Shop at ECS Tuning | ||||
| 04 | Cable covering f left seat carrier | 1 | 61131384819 | $5.19 | ENDED | Shop at ECS Tuning | ||||
| 04 | Cable covering for right seat carrier | 1 | 61131384820 | $5.19 | ENDED | Shop at ECS Tuning | ||||
| 05 | Cover, wheel housing, rear left | 1 | 61131384465 | $5.36 | ENDED | Shop at ECS Tuning | ||||
| For vehicles with CD-Radio |
=Yes |
|||||||||
| 05 | Yellow plug | 1 | 61131384492 | $6.47 | ENDED | Shop at ECS Tuning | ||||
| 06 | Cable cover for rear left wheel housing | 1 | 61131384467 | $3.24 | ENDED | Shop at ECS Tuning | ||||
| For vehicles with CD-Radio |
=Yes |
|||||||||
| 06 | Cable cover for rear right wheel housing | 1 | 61131384468 | $24.83 | ENDED | Shop at ECS Tuning | ||||
| 08 | Cable cover for floor panel, rear | 1 | 61131384000 | $2.18 | ENDED | Shop at ECS Tuning | ||||
| 10 | Push-button | 4 | 61131379831 | $0.97 | ENDED | Shop at ECS Tuning | ||||
| 11 | Push-button | SCHWARZ | 2 | 52101873545 | $1.34 | Shop at ECS Tuning | ||||
| 12 | Expanding rivet | 2 | 61131382239 | $0.23 | Shop at ECS Tuning | |||||
| For vehicles with Electr. window lifter |
=Yes |
|||||||||
| 13 | Left window lifter covering | 1 | 61131384723 | $2.68 | ENDED | Shop at ECS Tuning | ||||
| 13 | Right window lifter covering | 1 | 61131384724 | $2.95 | ENDED | Shop at ECS Tuning | ||||
| 14 | Expanding rivet | D=7,5MM | 6 | 51481915964 | $0.43 | Shop at ECS Tuning | ||||
| 15 | Push-button | ANTHRAZIT | 2 | 52101906933 | $0.41 | Shop at ECS Tuning | ||||
| 16 | Plastic nut for coarse threaded pin | M6 | 8 | 16131176747 | $0.53 | Shop at ECS Tuning | ||||
| For vehicles with CD-Radio and Auxiliary heating and Antenna-Diversity ONLY APPLIES TO HIFI SYSTEM |
=Yes =Yes =Yes |
|||||||||
| 18 | Cable cover for floor panel, front | 1 | 61131389390 | $6.47 | ENDED | Shop at ECS Tuning | ||||
| 19 | Cable cover for floor panel, rear | 1 | 61131389464 | $6.14 | ENDED | Shop at ECS Tuning | ||||
| 20 | Expanding nut | ST 6.3 | 1 | 64121379221 | $0.60 | Shop at ECS Tuning | ||||
Notes
- ENDED = the part has been discontinued (no longer available).
