Various switches for BMW 7 Series E23 732i (1982)
This Various switches technical drawing provides a detailed breakdown of the assembly for the 7 Series E23 732i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1982.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Cigarette lighter socket | 1 | 61341368728 | $48.94 | ENDED | Shop at ECS Tuning | ||||
| 02 | Compression spring | 1 | 61341362028 | $0.58 | ENDED | Shop at ECS Tuning | ||||
| 03 | Supporting ring | 1 | 61341357858 | ENDED | Shop at ECS Tuning | |||||
| ONLY APPLIES TO LIGHTER REAR | ||||||||||
| 04 | Cigarette lighter socket | 1 | 09/1982 | 61341363045 | $19.59 | Shop at ECS Tuning | ||||
| 04 | Cigarette lighter socket | 1 | 09/1982 | 61341363045 | $19.59 | Shop at ECS Tuning | ||||
| 05 | Bulb | 12V 1,2W | X | 63217167000 | $3.00 | Shop at ECS Tuning | ||||
| 06 | Lighter element | 2 | 61341364532 | $18.67 | Shop at ECS Tuning | |||||
| ONLY APPLIES TO LIGHTER REAR | ||||||||||
| 06 | Lighter element | 1 | 09/1982 | 61341364532 | $18.67 | Shop at ECS Tuning | ||||
| 06 | Lighter element | 1 | 09/1982 | 61341364532 | $18.67 | Shop at ECS Tuning | ||||
| 08 | Glow filament | 12 VOLT | 2 | 61348648111 | $5.27 | Shop at ECS Tuning | ||||
Notes
- ENDED = the part has been discontinued (no longer available).
