Various switches for BMW 3 Series E30 325e (1987)
This Various switches technical drawing provides a detailed breakdown of the assembly for the 3 Series E30 325e. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1987.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| For vehicles with National version japan |
L807A=Yes |
|||||||||
| 01 | Switch hand brake control | 1 | 61311369771 | $14.76 | Shop at ECS Tuning | |||||
| 02 | Fillister head screw | M4X10-Z5 | 1 | 51211916992 | $0.58 | ENDED | Shop at ECS Tuning | |||
| 03 | Switch | 2 | 61311368430 | $7.86 | Shop at ECS Tuning | |||||
| For vehicles with National version japan and Electr. window lifter |
L807A=Yes =Yes |
|||||||||
| 03 | Switch | 2 | 61311370805 | $8.98 | Shop at ECS Tuning | |||||
| For vehicles with National version japan |
L807A=Yes |
|||||||||
| 04 | Sheet-metal screw, black | ST4,2X13 | 3 | 07119901268 | $0.44 | Shop at ECS Tuning | ||||
| 06 | Expanding rivet | 1 | 46631241162 | $0.35 | Shop at ECS Tuning | |||||
| 07 | Bulb socket | 1 | 61131355640 | $3.63 | ENDED | Shop at ECS Tuning | ||||
| 08 | Bulb | 12V 1,2W | X | 63217167000 | $3.00 | Shop at ECS Tuning | ||||
| 09 | Door switch spacer | 2 | 61311370695 | $1.82 | Shop at ECS Tuning | |||||
Notes
- ENDED = the part has been discontinued (no longer available).
