Headlight cleaning system for BMW 8 Series E31 850Ci (1999)
This Headlight cleaning system technical drawing provides a detailed breakdown of the assembly for the 8 Series E31 850Ci. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1999.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Fluid container | 1 | 61661392326 | $73.80 | Shop at ECS Tuning | |||||
| For vehicles with AHK |
=Yes |
|||||||||
| 01 | Fluid container | 1 | 61668354279 | $62.78 | Shop at ECS Tuning | |||||
| 02 | Wash pump/fluid container | 1 | 61661377830 | Shop at ECS Tuning | ||||||
| 03 | Gasket | 1 | 61661365657 | $1.17 | Shop at ECS Tuning | |||||
| 03 | Rubber grommet with filter | 1 | 61678354271 | Shop at ECS Tuning | ||||||
| 05 | Hose clamp | 8-9.5MM | X | 16131379229 | $0.72 | Shop at ECS Tuning | ||||
| 06 | Hose line | D= 4,6MM | X | 61661357388 | $5.05 | Shop at ECS Tuning | ||||
| 07 | Cable grommet | 2 | 61131361918 | $1.58 | Shop at ECS Tuning | |||||
| 08 | Support | 2 | 61671392842 | $2.25 | ENDED | Shop at ECS Tuning | ||||
| 09 | Levelling switch wash container | 1 | 03/1996 | 61318360459 | $32.46 | Shop at ECS Tuning | ||||
| 10 | Rubber grommet | 1 | 61311369343 | $1.93 | Shop at ECS Tuning | |||||
| 11 | Hose line | D= 10MM | X | 61671379530 | $5.85 | Shop at ECS Tuning | ||||
| 12 | Washer | 40X4,8X2,5 | 1 | 31351117667 | $9.93 | ENDED | Shop at ECS Tuning | |||
| 13 | Hex nut | M8-8-ZNNIV SI | 1 | 07119905515 | $0.16 | Shop at ECS Tuning | ||||
| 14 | Pipe | 1 | 61671392327 | $32.70 | Shop at ECS Tuning | |||||
| 15 | Ring | 1 | 36311235570 | $1.18 | ENDED | Shop at ECS Tuning | ||||
| 16 | Plastic nut for coarse threaded pin | M6 | 5 | 16131176747 | $0.53 | Shop at ECS Tuning | ||||
| 17 | Grommet | 1 | 61671392501 | $1.80 | Shop at ECS Tuning | |||||
| 18 | Pipe | 1 | 61671392328 | $32.70 | Shop at ECS Tuning | |||||
| 19 | Cover | 1 | 61671392598 | $8.22 | Shop at ECS Tuning | |||||
| 20 | Gasket | 1 | 61678354177 | $1.13 | Shop at ECS Tuning | |||||
| 21 | Cable tie | L=292MM/B=4,8MM | 1 | 61131377134 | $0.77 | Shop at ECS Tuning | ||||
| 22 | Strainer | 1 | 61681386307 | $1.32 | ENDED | Shop at ECS Tuning | ||||
| 23 | Stick-on label | 9L | 1 | 61678354459 | $1.85 | ENDED | Shop at ECS Tuning | |||
| For vehicles with AHK |
=Yes |
|||||||||
| 23 | Stick-on label | 4,5L | 1 | 61678354465 | $0.70 | Shop at ECS Tuning | ||||
Notes
- ENDED = the part has been discontinued (no longer available).
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 8 Series E31 850Ci Headlight cleaning system?
- This technical diagram illustrates the Headlight cleaning system within the Vehicle electrical system group for the 8 Series E31 850Ci produced during 1999. It provides a detailed exploded view of the components, identifying key parts such as the Fluid container (Part #61661392326).
- Which models use the hardware listed in this Headlight cleaning system?
- The hardware and components featured in the Headlight cleaning system are specific to the 8 Series E31 850Ci produced during 1999. These technical specifications ensure that parts like the Fluid container (61661392326) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Headlight cleaning system assembly?
- Each item in the Headlight cleaning system corresponds to the numbered list below the illustration. For the 8 Series E31 850Ci, you can identify the Fluid container by locating its position on the schematic, which then links to the official BMW part number 61661392326 for the Vehicle electrical system section.
