Wiper for BMW 1502-2002tii 1802 (1974)
This Wiper technical drawing provides a detailed breakdown of the assembly for the 1502-2002tii 1802. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1974.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 02 | Wiring set | 1 | 61121353984 | $8.15 | ENDED | Shop at ECS Tuning | ||||
| 03 | Wiper switch | INTERVALL | 1 | 61311353870 | $109.65 | Shop at ECS Tuning | ||||
| 04 | Wiper-wash-interval control unit | 1 | 61311357904 | ENDED | Shop at ECS Tuning | |||||
| 06 | Switch | 1 | 08/1973 | 07/1977 | 61311357004 | $114.88 | ENDED | Shop at ECS Tuning |
Notes
- ENDED = the part has been discontinued (no longer available).
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 1502-2002tii 1802 Wiper?
- This technical diagram illustrates the Wiper within the Vehicle electrical system group for the 1502-2002tii 1802 produced during 1974. It provides a detailed exploded view of the components, identifying key parts such as the Wiring set (Part #61121353984).
- Which models use the hardware listed in this Wiper?
- The hardware and components featured in the Wiper are specific to the 1502-2002tii 1802 produced during 1974. These technical specifications ensure that parts like the Wiring set (61121353984) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Wiper assembly?
- Each item in the Wiper corresponds to the numbered list below the illustration. For the 1502-2002tii 1802, you can identify the Wiring set by locating its position on the schematic, which then links to the official BMW part number 61121353984 for the Vehicle electrical system section.
