Repair cable main cable harness for BMW 1 Series E88 128i (2013)
This Repair cable main cable harness technical drawing provides a detailed breakdown of the assembly for the 1 Series E88 128i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2013.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Rep. wiring harness, strut sector, left | 1 | 09/2008 | 61129206018 | Shop at ECS Tuning | |||||
| For vehicles with Active steering |
S217A=Yes |
|||||||||
| 01 | Rep. wiring harness, strut sector, left | 1 | 09/2008 | 61129206019 | Shop at ECS Tuning | |||||
| 02 | Rep. wiring harness, strut sector, right | 1 | 03/2010 | 61129238731 | Shop at ECS Tuning | |||||
| For vehicles with CO2 package |
S1CBA=Yes |
|||||||||
| 02 | Rep. wiring harness, strut sector, right | 1 | 03/2010 | 61129238727 | Shop at ECS Tuning | |||||
| 03 | Rep. wiring harness, front sector, left | 1 | 03/2011 | 61129261863 | Shop at ECS Tuning | |||||
| For vehicles with Adaptive Headlights |
S524A=Yes |
|||||||||
| 03 | Rep. wiring harness, front sector, left | 1 | 03/2011 | 61129261858 | Shop at ECS Tuning | |||||
| 04 | Rep. wiring harness, front sector, right | 1 | 03/2011 | 61129261864 | Shop at ECS Tuning | |||||
| For vehicles with Adaptive Headlights |
S524A=Yes |
|||||||||
| 04 | Rep. wiring harness, front sector, right | 1 | 03/2011 | 61129261853 | Shop at ECS Tuning | |||||
| 05 | Repair wiring for trunk lid | 1 | 09/2008 | 61129206138 | Shop at ECS Tuning | |||||
| 06 | Repair wiring kit for bumper, rear | 1 | 09/2007 | 61129182571 | $122.98 | Shop at ECS Tuning | ||||
| 07 | Rep. wiring harness washer fluid sector | 1 | 09/2008 | 61129206037 | $126.67 | Shop at ECS Tuning | ||||
| 08 | Wiring set PDC, front | 1 | 03/2012 | 61129283693 | Shop at ECS Tuning | |||||
| only in conjunction with | ||||||||||
| -- | Pin terminal | 12 POL./SCHWARZ | 1 | 03/2012 | 61138387220 | $5.75 | Shop at ECS Tuning | |||
